Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Product net weight | 45 kg | |
| Leveling foot maximum static load per foot | 25 kg | |
| Recommended user weight capacity | 130 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | 18mm particleboard core with 2mm ABS edge banding | |
|---|---|---|
| Desktop surface | Melamine laminate facing, scratch-resistant matte white | |
| Left side modesty panel | 18mm melamine-faced particleboard, full height solid panel | |
| Privacy divider panel | Fabric-upholstered fiberboard with light gray textured woven surface | |
| Support frame | 1.2mm thick powder-coated white steel leg and underframe | |
| Right pedestal body | 16mm melamine-faced particleboard with lockable drawer and cabinet door | |
| Leveling feet | Injection-molded plastic adjustable feet with non-slip base | |
| Cable grommets | Flexible plastic snap-in double-port grommets for cable routing | |
| Divider mounting brackets | White steel L-shaped clamps securing divider to desktop | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Privacy divider | Clamp-mounted fabric divider blocks line of sight between adjacent workstations | |
|---|---|---|
| Right pedestal storage | Integrated 1 lockable top drawer and 1 lower lockable cabinet for personal work items | |
| Cable management | Two sets of circular cable ports route power and data cables from desktop to floor | |
| Surface leveling | 4 adjustable plastic feet correct uneven floors with 10mm vertical adjustment | |
| Desktop worksurface | Flat smooth work surface supports monitor, laptop, and standard office equipment | |
| Modesty panel screening | Full-height left panel blocks view of user legs from side positions in open offices | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 1260 x 660 x 180 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office workstations | Suitable for multi-person open office layouts, with divider for visual privacy between seats | |
|---|---|---|
| Small home office use | Fits compact home workspaces for remote work and document storage | |
| Staff work areas | Appropriate for general administrative staff, with lockable storage for personal and work documents | |
| Startup office spaces | Cost-effective configuration for rapid office setup, with integrated cable management | |
| Reception back office areas | Usable for reception staff to complete administrative tasks out of customer view |
EU Market Access Requirements* EN Standards
| Office desk safety | EN 527:2011 | |
|---|---|---|
| Desk surface durability | EN 15372:2016 | |
| Office ergonomics | EN 527:2016 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Desk surface performance | GB/T 3324 | |
|---|---|---|
| Desk dimensional tolerance | GB/T 3326 | |
| Material formaldehyde emission | GB 18580 |
This product must meet the following technical requirements: 1. Desk surface performance: GB/T 3324; 2. Desk dimensional tolerance: GB/T 3326; 3. Material formaldehyde emission: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
