Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 2000 x 1400 x 1100 mm | |
|---|---|---|
| Worktop height from floor | 750 mm | |
| Per-user individual work surface | 1200 x 600 mm | |
| Knee clearance height under worktop | 650 mm | |
| Knee clearance depth (seat edge to modesty panel) | 450 mm | |
| Central privacy divider height above worktop | 350 mm | |
| Desktop panel thickness | 25 mm | |
| Side storage pedestal overall dimensions | 1200 x 400 x 1100 mm | |
| PVC edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Support leg wall section thickness | 2 mm | |
| Drawer internal usable depth | 350 mm | |
| Open shelf clearance height | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Total desk net weight | 90 kg | |
|---|---|---|
| Static uniform load capacity per work surface | 100 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge open/close cycle rating for cabinet doors | 80000 cycles | |
| Worktop surface abrasion resistance | 2000 cycles | |
| Recommended maximum user count | 2 | |
| Product warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | 25mm thick MFC engineered wood with melamine laminate | |
|---|---|---|
| Support frame and legs | Powder-coated matte grey steel with splayed tripod design | |
| Central privacy divider | Fabric-wrapped medium-density fiberboard core | |
| Edge banding | 2mm thick PVC edge trim applied to all exposed panel edges | |
| Storage pedestal carcass | 18mm thick melamine-faced particle board | |
| Drawer slides | Cold-rolled steel three-section full-extension ball-bearing slides | |
| Cable management ports | ABS plastic dual-port grommets with brush inserts | |
| Under-desk cable tray | Perforated powder-coated steel tray | |
| Adjustable foot pads | Nylon height-adjustable glides on pedestal base | |
| Drawer lock mechanism | Zinc alloy keyed cam lock | |
| Modesty panel | 18mm thick melamine-faced particle board | |
| Open shelf panels | 18mm thick melamine-faced particle board |
Adjustment / rotation / tilt / mobility / storage features
| Dual opposite-facing work zones | Two separate 1200x600mm work surfaces separated by central divider | |
|---|---|---|
| Integrated side storage system | Left-side pedestal combines lockable lower drawer, middle open shelf, upper hutch storage | |
| Dual-port cable management | Brush-lined grommets on pedestal face route cables from desktop to under-desk tray | |
| Full-extension drawer access | Three-section ball-bearing slides allow drawers to open fully 350mm | |
| Lockable secure storage | Keyed cam lock secures lower pedestal drawer | |
| Floor leveling adjustment | Nylon glides on pedestal base adjust up to 10mm | |
| Splayed tripod leg support | Angled steel legs on open end distribute weight evenly | |
| Fixed-height work surface | Worktop fixed at 750mm standard office height | |
| Stain-resistant worktop finish | Melamine laminate wipes clean with neutral detergent | |
| Modular connection compatibility | Frame includes pre-drilled connection points | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff zones | Suitable for high-density open office layouts, providing separated workspaces for two staff per unit | |
|---|---|---|
| Small team collaborative spaces | Ideal for startup or departmental teams requiring adjacent seated work positions with shared storage access | |
| Administrative and back-office areas | Appropriate for admin, finance or HR teams needing secure document storage and cable-managed work surfaces | |
| Coworking shared office spaces | Suitable for flexible coworking environments, providing durable fixed workstations with privacy and storage | |
| Government and public institution offices | Meets standard procurement specifications for public sector office furniture, with stable construction and secure storage | |
| Recommended matching furniture | Pair with two standard ergonomic mesh office chairs, 500 mm seat height | |
| Recommended surface clearance | Maintain 800mm clear circulation space behind each seating position |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office worktables safety and strength requirements, applicable to structural stability and load performance | |
|---|---|---|
| EN 1335-1:2000 | Office furniture ergonomic reference for desk height and clearance dimensions | |
| EN 15372:2008 | Furniture strength, durability and safety for non-domestic storage units, applicable to pedestal drawers |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products performance standard for load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for drawer cycle and load rating verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel worktop and storage components | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks, applicable to work surface height, load and stability specifications | |
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to MFC panel material structural performance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to engineered wood component safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel worktop and storage components; 2. GB/T 3327-2016: Technical requirements for office desks, applicable to work surface height, load and stability specifications; 3. GB/T 4897.3-2015: Particleboard for furniture use, applicable to MFC panel material structural performance; 4. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to engineered wood component safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
