PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Drawer front arrangement	One pencil drawer over one file drawer on each pedestal
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Static load per work surface	100 kg
Mobile pedestal load capacity	35 kg per unit
File drawer suspended load	20 kg
Recommended users	4 persons
Frame and top system net weight	118 kg
Mobile pedestal unit weight	24 kg
Caster rated load	40 kg per pedestal set
Warranty duration	5 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface construction	25 mm wood-grain high-pressure laminate board with sealed matching edge
Support frame	White powder-coated square steel tube legs and connecting rails
Modesty panels	Light gray laminate or powder-coated steel panels beneath the work surface
Central divider	Fabric-wrapped panel over an engineered board or steel frame
Mobile pedestals	Light gray body with wood-grain drawer and top accents
Casters and hardware	Black twin-wheel nylon casters with steel mounting stems and ball-bearing drawer slides

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Four-user benching layout	Two work surfaces are joined face-to-face to provide four outward-facing seating positions
Visual privacy divider	A central low screen separates opposite users and reduces direct sight lines while leaving overhead communication open
Mobile personal storage	Each caster-mounted pedestal can roll under the work surface and be pulled out for access or repositioning
File and stationery storage	Each pedestal uses an upper shallow drawer and lower file drawer for personal supplies and hanging documents

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Main carton dimensions	1280 x 660 x 140 mm
Pedestal carton dimensions	520 x 440 x 650 mm per pedestal carton
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office cluster	Suits four-person team zones where users need individual seating space, low visual separation, and personal mobile storage
Procurement configuration	Pair with four task chairs and two pedestals for complete departments, call centers, or administrative workgroups

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office desk safety and strength	EN 527:2011 safety, strength, and durability requirements
Office desk dimensional assessment	EN 527:2003 dimensional requirements for work surfaces and clearance
Office storage safety	EN 14073:2004 safety requirements for office storage furniture
Fabric upholstery burning behavior	EN 1021cigarette and EN 1021 match ignition tests

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Desk structural durability	ANSI/BIFMA X5.5 desk strength, fatigue, and stability tests
Mobile pedestal durability	ANSI/BIFMA X5.3 vertical file test requirements
Floor glide and caster durability	ANSI/BIFMA X5.1 caster and base durability methods adapted for mobile storage

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Formaldehyde emission verification	GB/T 39600E1 limit for wood-based panel components
Steel furniture structural test	GB/T 3324strength, stability, and dimensional inspection criteria
Fire safety for interior fabrics	GB 8624 B1 flame-retardant classification for the divider fabric if specified

Standardized tender description text

This product must meet the following technical requirements:
1. Formaldehyde emission verification: GB/T 39600E1 limit for wood-based panel components;
2. Steel furniture structural test: GB/T 3324strength, stability, and dimensional inspection criteria;
3. Fire safety for interior fabrics: GB 8624 B1 flame-retardant classification for the divider fabric if specified;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-4P-WO-2400x1200-MP

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-4P-WO-2400x1200-MP

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-4P-WO-2400x1200-MPOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Four-Person Panel Workstation with Two Mobile Pedestals is an unbranded office benching solution designed for team-based work areas. Its model reference is WS-4P-WO-2400x1200-MP. The layout joins two work surfaces face-to-face, producing four outward-facing seating positions with a central fabric-covered divider between opposite users. The low screen reduces direct sight lines and provides modest visual separation while preserving easy overhead communication. Its overall presentation combines wood-grain laminate work surfaces, light gray modesty panels, a white powder-coated steel frame, and light gray mobile pedestals with wood-grain drawer and top accents, giving the workstation a structured, contemporary office appearance. Construction is based on 25 mm wood-grain high-pressure laminate board with a sealed matching edge and a finished top thickness of 50 mm. The support structure uses white powder-coated square steel tube legs and connecting rails, with an 80 mm main leg section and 2 mm metal wall. Beneath the work surface, light gray laminate or powder-coated steel modesty panels add visual screening. The central divider consists of fabric-wrapped paneling over an engineered board or steel frame. Black twin-wheel nylon casters with steel mounting stems and ball-bearing drawer slides support the mobile storage units. Each main seat offers 680 mm of knee clearance height and 900 mm of knee clearance width. Cable management is integrated through an 80 mm cable opening and a cable tray with 120 mm of depth. Each work surface is rated for a 100 kg static load. The two included pedestals roll under the work surface and can be pulled out for access or repositioned as needed. Every pedestal has one shallow pencil drawer above one file drawer, supporting stationery storage and hanging document filing. The mobile pedestal load capacity is 35 kg per unit, the file drawer suspended load is 20 kg, and the caster set is rated for 40 kg per pedestal. This configuration is well suited to open-plan four-person team zones that require individual work space, low visual separation, and personal mobile storage. It is appropriate for departments, call centers, administrative workgroups, and residential office settings where multiple users share a coordinated workspace. For a complete setup, the workstation can be paired with four task chairs and its two included pedestals. Procurement planning should account for the four-person capacity, the two pedestal configuration, and the need to place the unit on level flooring suitable for casters. The frame and top system weighs 118 kg net, each mobile pedestal weighs 24 kg, and the reference packaged gross weight is 180 kg per set. Reference assembly time is 40 minutes per set. Buyers should review packing details before delivery, as supplied logistics information lists both a two-carton reference and a four-carton reference with separate pedestal packaging.

Four-Person Panel Workstation with Two Mobile Pedestals Specifications
