Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 135 kg | |
|---|---|---|
| Worktop static load capacity per seat | 80 kg | |
| Recommended maximum user weight per seat | 110 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended occupancy | 4 users | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 25mm E1 grade particleboard with oak-pattern melamine laminate | |
|---|---|---|
| Frame legs and support beams | 1.5mm thick powder-coated light grey steel tube | |
| Privacy dividers | 18mm MDF panel with off-white matte melamine finish | |
| Pedestal side and back panels | 16mm E1 grade particleboard with light grey melamine finish | |
| Drawer and cabinet door fronts | 18mm E1 grade particleboard with matching oak melamine finish | |
| Drawer upper front trim | 18mm MDF with off-white matte melamine finish | |
| Mounting and pull hardware | Zinc alloy with orange powder-coated finish | |
| A-frame decorative panel | 18mm particleboard with matching oak melamine finish | |
| Drawer slides | Cold-rolled steel three-section full extension slides | |
| Leveling feet | Nylon base with steel threaded stem | |
| Edge banding | 1mm thick PVC edge banding matching panel finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Privacy divider function | 350mm high off-white dividers separate opposite seated users | |
|---|---|---|
| Cable management groove | 300mm wide recessed channel at base of each divider | |
| Upper drawer storage | 150mm high shallow drawer per pedestal | |
| Lower cabinet storage | 500mm high lockable door cabinet per pedestal | |
| Integrated storage support | Dual floor-standing pedestals act as central structural supports | |
| A-frame leg design | Angled steel leg assembly at open desk end | |
| Leveling foot adjustment | 10mm height adjustment on all floor contact points | |
| Locking storage function | Keyed lock per pedestal secures both drawer and cabinet | |
| Modular configuration compatibility | Desk can be joined to identical units for larger open-plan teams | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Four-person configuration fits standard open office layouts for collaborative teams | |
|---|---|---|
| Corporate department work zones | Suitable for admin, sales or operations teams requiring adjacent shared workspaces | |
| Co-working space dedicated desks | Durable commercial construction supports frequent daily use in shared work environments | |
| Small business office setups | All-in-one design eliminates need for separate desks, dividers and storage units | |
| Startup team work areas | Modular design allows reconfiguration as team size changes | |
| Training and project team spaces | Dual face-to-face seating supports small group project work and discussion |
EU Market Access Requirements* EN Standards
| Office furniture stability | EN 527:2002 | |
|---|---|---|
| Formaldehyde emission | EN 13986:2004 E1 class | |
| Surface wear resistance | EN 14322:2017 |
US and Canada office-furniture standards
| Desk load and stability | ANSI/BIFMA X2021 | |
|---|---|---|
| Storage unit performance | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Panel formaldehyde emission | GB/T 39600E1 grade | |
|---|---|---|
| Desk structural strength | GB/T 3324 | |
| Hardware durability | GB/T 10357.5 | |
| Surface coating adhesion | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Panel formaldehyde emission: GB/T 39600E1 grade; 2. Desk structural strength: GB/T 3324; 3. Hardware durability: GB/T 10357.5; 4. Surface coating adhesion: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
