Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions | 2400 x 600 x 750 mm | |
|---|---|---|
| Per-user work surface area | 1200 x 600 mm | |
| Privacy divider dimensions per position | 1100 x 350 mm | |
| Divider mounting height above worktop | 200 mm | |
| Under-desk knee clearance height | 673 mm | |
| Knee clearance width per user | 1100 mm | |
| Mobile storage pedestal dimensions | 400 x 550 x 699 mm | |
| Worktop thickness | 38 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel leg cross-section dimension | 44 mm square | |
| Cable grommet diameter | 60 mm | |
| Drawer internal file compartment dimensions | 305 x 387 x 241 mm | |
| Caster diameter on mobile pedestals | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Distributed static load per work surface | 150 kg | |
|---|---|---|
| Mobile pedestal drawer slide static load per drawer | 25 kg | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Worktop surface abrasion resistance | 2000 revolutions | |
| Seating capacity | 2 users | |
| Product net weight | 154 kg | |
| Undercounter cable tray load capacity | 10 kg | |
| Warranty period | 5 years | |
| Available finish color options | 6 standard colors | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core | E1-grade melamine-faced particle board | |
|---|---|---|
| Worktop finish | Thermally fused scratch-resistant melamine laminate | |
| Worktop edge protection | 2mm thick impact-resistant PVC edge banding | |
| Support frame and legs | Powder-coated matte white steel | |
| Privacy divider panels | Textured terracotta-finish MDF | |
| Mobile storage pedestals | Melamine-laminated particle board carcass | |
| Pedestal hardware | Steel drawer slides, lockable file drawer with key lock | |
| Pedestal casters | Dual-wheel nylon swivel casters | |
| Cable management components | ABS plastic cable grommets, optional steel under-desk cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Desktop visual privacy | Low divider panels block direct line of sight between adjacent users | |
|---|---|---|
| Mobile storage mobility | Pedestals roll freely on casters for repositioning under desk or adjacent use | |
| Drawer locking system | Central key lock secures all three drawers on each pedestal | |
| Cable routing | Recessed cable grommets allow clean routing of monitor power and data cables | |
| Storage configuration per pedestal | 1 shallow stationery drawer, 2 deep hanging file drawers | |
| Fixed work surface height | 750mm fixed standing height optimized for standard ergonomic task chairs | |
| Stable leg design | Splayed angled end legs distribute weight evenly across floor | |
| Modular expandability | Workstation can be connected to adjacent matching units for larger open-office bench layouts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office work areas | Ideal for corporate open offices, providing two dedicated workstations with low distraction dividers | |
|---|---|---|
| Startup and co-working spaces | Modular design supports flexible team seating arrangements with dedicated per-user storage | |
| Small business admin areas | Compact footprint fits two staff work positions without requiring excessive floor space | |
| Call center and back-office spaces | Durable construction supports high-frequency daily use for shift-based staff | |
| Recommended pairing | Matches with ergonomic mid-back mesh task chairs with 520 mm adjustable seat height | |
| Floor surface compatibility | Suitable for hard tile, vinyl and low-pile carpet flooring with non-marking leg feet and casters |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance verification | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety requirements, applicable to clearance and ergonomic dimensions | |
| EN 1335-1:2020 | Office furniture work chair dimensional compatibility, applicable to knee clearance fit |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to mobile pedestal durability and load |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate worktop and storage components | |
|---|---|---|
| GB/T 3327-2020 | Performance standards for office desks, applicable to structural load and stability requirements | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to board emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate worktop and storage components; 2. GB/T 3327-2020: Performance standards for office desks, applicable to structural load and stability requirements; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to board emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
