PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1680 × 800 × 750 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Static work surface load capacity	120 kg
Net weight (assembled)	78 kg
Recommended user weight capacity	136 kg
Surface abrasion resistance	2000 cycles
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test
Recommended Procurement Warranty	Structure 5 years; hardware 3 years; finish 2 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25mm E1-grade particleboard with walnut-melamine finish, sealed PVC edge banding
Support legs	Tapered square powder-coated matte light grey steel, 2mm wall thickness
Storage cabinet carcass	18mm E1-grade particleboard with warm beige and walnut matching melamine finish
Top drawer front	18mm melamine-faced particleboard with built-in combination lock
Desktop privacy screen	Fabric-wrapped high-density fiberboard with rounded edges, pale yellow finish
Cabinet leveler feet	Nylon-tipped steel adjustable feet, 10mm adjustment range
Desk edge banding	2mm thick PVC edge banding matching work surface color, impact-resistant
Drawer slides	Full-extension cold-rolled steel side-mount slides, zinc-plated finish
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm
Metal Frame Wall Thickness	2 mm cold-rolled steel
Primary Connector Specification	Reference M6-M8 with at least 2 fixing points per main support

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Desktop privacy screen	Fixed curved fabric screen divides adjacent workstations, reduces visual distraction
Top drawer lock	Integrated keyed lock secures top drawer for private storage of valuables
Open under-desk cubby	Floor-accessible open storage compartment holds personal items or CPU tower
Full-extension top drawer	Drawer slides allow full access to stored stationery and documents, soft-close mechanism
Cable management access	Recessed cable port behind privacy screen routes power and data cables to floor outlets
Adjustable leveling feet	Cabinet and leg feet adjust up to 10mm to stabilize desk on uneven carpet or hard flooring
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office workstations	Single-sided design with privacy screen supports focused individual work in shared open offices
Executive private offices	Integrated storage and premium finish suit mid-level manager private workspaces
Small business office spaces	Compact 1680mm width fits small office footprints without sacrificing work surface area
Co-working space dedicated desks	Lockable drawer and integrated storage provide secure personal storage for dedicated co-working members
Home office workspaces	Neutral two-tone finish and compact size fit residential office spaces for remote work

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office worktables safety and strength requirements, applicable for structural performance verification
EN 527-2:2016	Office worktables dimensional and ergonomic requirements, applicable to clearance and surface height

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products safety and performance standard, applicable to load and durability testing

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to desk top and cabinet panel components
GB/T 3325-2017	General technical requirements for metal furniture, applicable to steel support leg structure
GB 18580-2017	Formaldehyde emission limit for wood-based panels, applicable to all particleboard components

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk top and cabinet panel components;
2. GB/T 3325-2017: General technical requirements for metal furniture, applicable to steel support leg structure;
3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to all particleboard components;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFDSK-STG-1680

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFDSK-STG-1680

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFDSK-STG-1680Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Modern Single-Sided Office Workstation with Integrated Storage Pedestal (model OFDSK-STG-168) presents a streamlined, purpose-built workspace solution defined by clean, contemporary lines and a cohesive two-tone neutral finish. Its layout orients the primary work surface toward the user, with a fixed curved fabric-wrapped privacy screen along one edge to separate adjacent positions, and a matching storage pedestal integrated seamlessly below the desktop to eliminate disjointed accessory clutter. The warm walnut melamine work surface pairs with warm beige and walnut storage finishes, complemented by matte light grey tapered steel legs and a soft pale yellow privacy screen for a polished, understated visual profile. Constructed for long-term daily use, the workstation features an impact-resistant work surface made of E1-grade particleboard sealed with color-matched PVC edge banding, supported by a powder-coated steel frame with 2mm wall thickness. Its built-in storage pedestal uses E1-grade particleboard for its carcass, with a top drawer fitted with an integrated keyed lock and full-extension zinc-plated cold-rolled steel slides with a soft-close mechanism. Nylon-tipped steel adjustable feet sit at the base of both legs and storage cabinet, and the work surface incorporates a recessed cable port paired with an under-desk cable tray. An open under-desk cubby sits at floor level, accessible without bending to reach enclosed storage. Functional features support focused, organized work: the curved privacy screen reduces visual distraction in shared settings, the lockable top drawer secures personal valuables and sensitive documents, the full-extension drawer allows unobstructed access to stored stationery and files, and the cable management system routes power and data cords neatly to floor outlets. Adjustable feet stabilize the unit on uneven carpet or hard flooring, while the open cubby accommodates personal items or a CPU tower. This workstation fits a range of commercial and residential spaces, including open-plan office layouts, mid-level executive private offices, small business offices, dedicated co-working desks, and residential home offices for remote work. Procurement teams should note that each unit ships across multiple cartons, requires on-site assembly, and balances compact footprint with sufficient work surface and storage capacity to serve both shared and dedicated workspace needs.
