Single-Sided Office Workstation Desk with Attached Storage Pedestal and Privacy Divider (model OWS-1400-SW) is listed under Open Workstation, with overall dimensions of 1400 × 700 × 750 mm and main material of Particle‑board (PB). Load capacity: 100 kg. Certifications: modern,design,fixed-height,attached,storage,pedestal,desk-mounted,privacy,screen,cable,management. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1400 x 700 x 750 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Knee clearance height | 620 mm | |
| Knee clearance width | 900 mm | |
| Privacy screen height above desktop | 300 mm | |
| Attached storage pedestal dimensions | 500 x 550 x 650 mm | |
| Lower cabinet door internal height | 480 mm | |
| Cable vent cutout diameter | 80 mm | |
| Tapered leg diameter at floor contact | 40 mm | |
| Desk handle length | 120 mm | |
| Phone holder slot dimensions | 80 x 160 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for cabinet door | 80000 cycles | |
| Net weight | 55 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Maximum user weight recommendation | 120 kg | |
| Surface stain and moisture resistance | Commercial grade | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop and storage panels | 25mm melamine-faced MFC particle board, E0 grade core | |
|---|---|---|
| Support legs | Solid oak veneer engineered wood, tapered angled profile | |
| Privacy divider | Fabric-wrapped MDF core with teal finish, integrated phone slot | |
| Storage front panels | 18mm white melamine-faced MDF, light wood pull handles | |
| Edge banding | 2mm PVC matching worktop finish, sealed all panel edges | |
| Hardware components | Zinc-alloy lock, steel ball-bearing slides, steel support feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lockable upper drawer | Integrated key lock secures stationery and small office supplies | |
|---|---|---|
| Cable management ventilation | Dual slotted vents on pedestal side for CPU/device airflow and cable routing | |
| Desk-mounted privacy screen | Rear-edge mounted divider reduces visual distraction with integrated phone holder slot | |
| Fixed work height | 750 mm standard office height compatible with standard task chairs |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Shipping carton dimensions | 1480 x 780 x 180 mm | |
|---|---|---|
| Gross shipping weight | 70 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff workstations | Single-sided layout suits individual seated work with visual privacy divider | |
|---|---|---|
| Home office dedicated workspace | Compact footprint and modern finish suit residential home office setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office work desk dimensional, strength and stability requirements | |
|---|---|---|
| EN 14073-2:2004 | Applies to office storage furniture safety and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products strength, durability and stability requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applies to office storage units performance and safety requirements |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, strength and durability requirements | |
|---|---|---|
| GB/T 3327-2016 | Applies to office storage cabinet strength and stability requirements | |
| GB 18580-2017 | Applies to formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, strength and durability requirements; 2. GB/T 3327-2016: Applies to office storage cabinet strength and stability requirements; 3. GB 18580-2017: Applies to formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
