Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4800 x 1600 x 750 mm | |
|---|---|---|
| Per-workstation width | 1600 mm | |
| Per-side worktop depth | 800 mm | |
| Seated knee clearance height | 600 mm | |
| Privacy divider height above worktop | 350 mm | |
| Privacy divider thickness | 32 mm | |
| Worktop thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Integrated pedestal dimensions | 404 x 520 x 600 mm | |
| Steel leg tube thickness | 2 mm | |
| Levelling foot adjustment range | 15 mm | |
| CPU storage slot dimensions | 250 x 500 x 500 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per-workstation static load capacity | 135 kg | |
|---|---|---|
| Per-pedestal drawer static load | 30 kg | |
| Total assembly static load | 810 kg | |
| Worktop surface scratch resistance | 2000 cycles | |
| Recommended user capacity | 6 people | |
| Product net weight (total) | 380 kg | |
| Drawer lock cycle durability | 10000 cycles | |
| Frame rust resistance | 500 hours salt spray | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 25mm E0 grade melamine-faced particleboard | |
|---|---|---|
| Worktop edge trim | 2mm impact-resistant PVC edge banding | |
| Support frame and legs | 2mm powder-coated off-white steel with angled tapered profile | |
| Privacy divider core | 32mm polyester fiber acoustic panel | |
| Privacy divider upholstery | Woven polyester fabric with light gray matte finish | |
| Pedestal cabinet body | 0.7mm cold-rolled steel with off-white powder coat | |
| Drawer slides | Full-extension ball-bearing steel slides | |
| Levelling feet | Reinforced nylon with steel threaded stem | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Modular connection system | Pre-drilled steel brackets link adjacent desk sections for layout expansion | |
|---|---|---|
| Cable management access | Scalloped cutouts at worktop rear route power/data cables below surface | |
| Pedestal drawer locking system | Central key lock secures all 3 drawers per pedestal to secure personal items | |
| Anti-tilt drawer mechanism | Prevents opening more than one drawer at a time to avoid tip-over risk | |
| Height-adjustable levelling feet | 15mm travel compensates for uneven floors to keep worktop level | |
| CPU open storage slots | Adjacent open compartments between pedestals house desktop computer towers | |
| Privacy divider mounting | Bracket-fixed dividers sit centrally between opposite seats to reduce visual distraction | |
| Surface stain resistance | Thermally fused melamine finish resists common office liquid spills and stains | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office areas | Provides dedicated individual workspaces with reduced visual distraction for teams of 6 | |
|---|---|---|
| Co-working flexible offices | Modular construction allows reconfiguration as team sizes change | |
| Corporate staff work zones | Integrated storage saves floor space for administrative and operational teams | |
| Startup office environments | Modern minimalist aesthetic matches contemporary office interior design schemes | |
| Call center work floors | Consistent standardized seating positions support high-density staff deployment | |
| Recommended pairing | Match with mesh-back height-adjustable task chairs on casters for ergonomic use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and strength requirements | |
| EN 1335-2:2009 | Office chair safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and durability standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage cabinets and pedestals performance standard | |
| ANSI/BIFMA M7.1-2020 | Standard test method for furniture VOC emissions |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3325-2017 | Metal office furniture general technical requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3325-2017: Metal office furniture general technical requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
