Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Individual work zone size | 1200 x 600 mm | |
| Work surface thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Privacy divider height above work surface | 400 mm | |
| Privacy divider thickness | 25 mm | |
| Knee clearance height under work surface | 650 mm | |
| Knee clearance width per seated position | 600 mm | |
| Integrated pedestal dimensions per seat | 600 x 500 x 600 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Steel support leg wall thickness | 1.5 mm | |
| Adjustable leveling foot height adjustment range | 15 mm | |
| Total workstation height including dividers | 1150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Work surface static load capacity | 120 kg | |
|---|---|---|
| Recommended maximum user weight per station | 110 kg | |
| Desk net weight (fully assembled) | 185 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1-grade melamine-faced particleboard, scratch-resistant matte white finish | |
|---|---|---|
| Edge banding | 2mm thick impact-resistant PVC, rounded safety corners | |
| Support frame and legs | 1.5mm thick cold-rolled steel, white electrostatic powder coating | |
| Privacy dividers | 25mm thick frosted semi-translucent acrylic, polished edges, white mounting brackets | |
| Pedestal cabinet panels | 18mm thick E1 melamine particleboard, matching white finish | |
| Drawer slides | 3-section full-extension ball-bearing steel, silent soft-close mechanism | |
| Cabinet hinges | Cold-rolled steel concealed hinges, 110-degree opening angle | |
| Locks | Keyed-alike brass core cylinder locks, one key per pedestal | |
| Leveling feet | Nylon base with steel threaded stem, chrome finish | |
| Cable grommets | ABS plastic, brushed silver finish, removable cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Privacy screening | Two low frosted dividers separate four work zones to reduce visual distraction between seated users | |
|---|---|---|
| Per-seat storage | Each station includes one lockable upper drawer and one lower lockable cabinet door for personal office storage | |
| Cable management | Desktop grommets at each station route power and data cables from surface devices to under-desk space | |
| Floor leveling | Adjustable threaded feet compensate for uneven floors to keep the work surface stable and level | |
| Modular expansion | Bench construction supports connection to additional matching workstations for larger open-plan office layouts | |
| Secure storage | Keyed locks restrict access to personal documents and office supplies stored in each pedestal | |
| Surface protection | Melamine finish resists stains, scratches, and heat from standard office equipment like laptops and monitors | |
| Quiet operation | Soft-close drawer slides and hinges reduce noise in open office environments during storage access | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Suitable for 4 seated employees in corporate open workspaces with integrated personal storage | |
|---|---|---|
| Startup and co-working spaces | Modular design supports flexible team seating arrangements with built-in cable management for devices | |
| Administrative and departmental work zones | Provides dedicated individual work zones with reduced visual distraction from low dividers | |
| Call center and back-office operations | Durable construction and lockable storage support daily high-utilization office use | |
| Educational institution staff offices | Configurable multi-seat layout works for university and research administration work areas | |
| Recommended companion seating | Pairs with standard mid-back ergonomic office chairs with 480 mm seat height for proper ergonomic alignment |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable to desk height and clearance requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables - Part 2: Mechanical safety requirements, applicable to stability and load performance | |
| EN 13722:2004 | Office furniture - Storage units, applicable to pedestal drawer and cabinet performance | |
| EN 15372:2008 | Furniture - Durability requirements for office tables, applicable to structural cycle testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard, applicable to work surface load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard, applicable to pedestal drawer slide and hinge cycle testing | |
| ANSI/BIFMA X7.1-2020 | Formaldehyde emission standard for low-emitting office furniture materials | |
| ANSI/BIFMA e3-2020 | Sustainability standard for commercial office furniture, applicable to material and emissions criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and storage construction | |
|---|---|---|
| GB/T 3327-2017 | Performance test methods for office desks, applicable to structural stability and load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade board materialAcceptance | |
| GB/T 4897.3-2003 | Requirements for particleboard used in furniture, applicable to desk and pedestal panel substrates |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and storage construction; 2. GB/T 3327-2017: Performance test methods for office desks, applicable to structural stability and load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade board materialAcceptance; 4. GB/T 4897.3-2003: Requirements for particleboard used in furniture, applicable to desk and pedestal panel substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
