Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2700 x 1200 x 1120 mm | |
|---|---|---|
| work surface height | 800 mm | |
| central privacy screen height above floor | 1200 mm | |
| privacy screen thickness | 32 mm | |
| desktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| knee clearance height under work surface | 650 mm | |
| knee clearance depth per workstation | 600 mm | |
| mobile drawer pedestal dimensions | 400 x 500 x 600 mm | |
| support leg diameter | 60 mm | |
| cable grommet diameter | 80 mm | |
| monitor riser mount height above desk | 220 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| total uniform static desktop load | 300 kg | |
|---|---|---|
| desktop deflection at full load | 1.5 mm | |
| per drawer static load capacity | 30 kg | |
| drawer slide open/close durability | 5000 cycles | |
| product net weight | 68 kg | |
| recommended user capacity | 2 users | |
| surface abrasion resistance | 2000 cycles | |
| warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop substrate | E1-grade particle board | |
|---|---|---|
| desktop surface finish | Scratch-resistant melamine laminate | |
| edge banding | 2mm thick PVC edging | |
| support legs | Powder-coated cold-rolled steel cylindrical tubes | |
| privacy divider panel | Fabric-faced sound-dampening panel with aluminum edge frame | |
| drawer pedestals | 0.8mm thick cold-rolled steel cabinet body | |
| pedestal casters | 50mm diameter hard nylon swivel casters | |
| drawer slides | 3-section full-extension ball-bearing soft-close slides | |
| cable grommets | ABS plastic recessed cable pass-throughs | |
| hardware components | Zinc-plated steel bolts and cam locks | |
| rear monitor mounts | Powder-coated steel bracket risers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| face-to-face dual workstation layout | Two separate seated work positions separated by a central privacy screen for two staff members | |
|---|---|---|
| mobile storage pedestals | Two 4-drawer caster-mounted pedestals positioned under the rear work surface for movable file storage | |
| integrated cable management | Recessed desk grommets route power and data cables from desk surface to under-desk runs | |
| lockable caster function | Two lockable casters per mobile pedestal prevent unintended movement during daily use | |
| soft-close drawer operation | Drawer slides engage damping mechanism in final 50mm of travel to prevent slamming | |
| modular expandable design | Cluster can connect to additional matching workstations to form larger open-plan office layouts | |
| surface easy maintenance | Melamine desktop resists common office stains and wipes clean with standard disinfectants | |
| elevated rear equipment mounting | Fixed rear brackets support monitor risers or desk organizers without occupying primary work area | |
| ergonomic knee clearance | Open unobstructed front knee well allows standard office chair adjustment for seated users | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open-plan office staff zones | Suitable for general administration, customer service or data entry teams in commercial offices | |
|---|---|---|
| small business startup offices | Compact dual-user layout fits small footprint work areas without requiring custom installation | |
| shared coworking spaces | Modular design supports flexible seating arrangements for hot-desking environments | |
| team department work areas | Clusters can be grouped to form 4, 6 or 8 person teams for departmental seating | |
| back-office operation centers | Durable construction supports long daily use in high-activity administrative areas | |
| temporary project workspaces | Disassemblable flat-pack design allows quick reconfiguration for short-term project teams |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety and stability, applicable to ergonomic clearance requirements | |
| EN 1335-1:2020 | Office furniture office chairs dimensional reference, applicable to matching desk-chair ergonomic fit | |
| EN 71-3:2019 | Migration of certain elements, applicable to surface finish safety for office environments |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to mobile drawer pedestal durability and load rating | |
| ANSI/BIFMA X5.6-2022 | Panel systems standard, applicable to privacy divider strength and stability requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and frame performance | |
|---|---|---|
| GB/T 3327-2017 | Office furniture desks and tables, applicable to dimensional and stability requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to desktop substrate E1 compliance | |
| GB/T 4897.3-2015 | Particle board for furniture use, applicable to desktop substrate material grading |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and frame performance; 2. GB/T 3327-2017: Office furniture desks and tables, applicable to dimensional and stability requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to desktop substrate E1 compliance; 4. GB/T 4897.3-2015: Particle board for furniture use, applicable to desktop substrate material grading; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
