Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions (6-person double-sided) | 7200 x 1500 x 1100 mm | |
|---|---|---|
| Individual work surface width per seat | 1200 mm | |
| Work surface depth per side | 750 mm | |
| Finished work surface height from floor | 750 mm | |
| Worktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Low integrated shelf divider total height | 1100 mm | |
| Shelf divider panel thickness | 32 mm | |
| Under-desk knee clearance height | 680 mm | |
| Under-desk pedestal dimensions per seat | 400 x 600 x 500 mm | |
| Angled steel leg section size | 60 x 30 mm | |
| Cable grommet diameter | 80 mm | |
| Adjustable levelling foot height adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Static uniform load capacity per work surface | 300 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Door/drawer hinge cycle rating | 80000 cycles | |
| Recommended user weight limit per seat position | 150 kg | |
| Workstation net weight per individual seat module | 75 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | E1 grade melamine-faced chipboard | |
|---|---|---|
| Work surface finish | Light oak scratch-resistant melamine laminate | |
| Edge banding | 2mm thick impact-resistant PVC edging | |
| Support frame and legs | Powdercoated beige steel tube | |
| Stability cross bracing | 2mm thick powdercoated steel bar | |
| Divider shelves and cabinet panels | 18mm thick melamine-faced chipboard | |
| Pedestal drawer fronts | Matte light gray and light oak melamine | |
| Levelling feet | Nylon base with steel threaded stem | |
| Included task chair upholstery | Breathable polyester mesh back, fabric seat | |
| Task chair frame components | White powdercoated nylon and steel frame | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Modular configuration capability | Supports 2/4/6/8 person linear or double-sided layouts | |
|---|---|---|
| Integrated divider storage | Two open shelf tiers per divider for binders and desk accessories | |
| Under-desk pedestal storage per seat | One shallow stationery drawer and one lockable file drawer | |
| Cable management system | Desktop grommets with under-desk cable tray routing | |
| Leg levelling adjustment | 15mm threaded foot adjustment to correct uneven floors | |
| Anti-tilt drawer mechanism | Prevents more than one drawer from opening at a time | |
| Work surface connection system | Cam-lock and metal bracket assembly for rigid modular joints | |
| Privacy divider function | 350mm above-desk divider height to reduce visual distraction without blocking light | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan corporate office spaces | Designed for high-density team work areas with low visual distraction and shared infrastructure | |
|---|---|---|
| Startup and co-working environments | Modular layout adapts to changing team sizes and flexible work arrangements | |
| Project team collaboration zones | Low dividers support both individual focused work and impromptu team communication | |
| Education and training staff offices | Durable commercial construction withstands high daily use in institutional settings | |
| Recommended paired equipment | Mid-back mesh ergonomic task chairs, monitor arms, and under-desk cable management accessories |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables: safety and strength requirements for commercial desk performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables: dimensional and ergonomic requirements for seated work | |
| EN 15372:2016 | Office furniture: storage units, applicable to under-desk pedestal strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.3-2022 | Vertical files standard, applicable to under-desk pedestal drawer performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and storage panel quality | |
|---|---|---|
| GB/T 3327-2016 | Office furniture: desks, applicable to dimensional and structural performance requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MFC substrate selection | |
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to worktop and cabinet substrate specifications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and storage panel quality; 2. GB/T 3327-2016: Office furniture: desks, applicable to dimensional and structural performance requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MFC substrate selection; 4. GB/T 4897.3-2015: Particleboard for furniture use, applicable to worktop and cabinet substrate specifications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
