| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall cluster dimensions | 2800 x 2700 x 1100 mm | |
|---|---|---|
| Work surface height from floor | 750 mm | |
| Per individual work surface | 1200 x 600 mm | |
| Desktop privacy screen height | 300 mm | |
| Central storage divider width | 400 mm | |
| Under-desk knee clearance height | 680 mm | |
| Top panel thickness | 25 mm | |
| Divider and carcass panel thickness | 16 mm | |
| PVC edge banding thickness | 2 mm | |
| Tapered steel leg diameter at base | 30 mm | |
| Central drawer internal usable dimensions | 450 x 350 x 120 mm | |
| Open central shelf compartment height | 250 mm | |
| Cable pass-through clip diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Whole workstation static load capacity | 400 kg | |
|---|---|---|
| Per work surface uniform static load | 100 kg | |
| Workstation net weight | 180 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| PVC edge impact resistance rating | 2 Nm | |
| Number of supported users | 4 | |
| Steel frame rust resistance coating life | 3 years | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | E1-grade melamine-faced particleboard, light oak/light grey finish | |
|---|---|---|
| Central divider and storage carcass | Melamine-faced MDF, dark charcoal grey finish | |
| Drawer fronts | Melamine-faced engineered wood, matching light worktop finish | |
| Support legs | Powder-coated dark grey tapered steel, anti-slip plastic foot caps | |
| Edge banding | 2mm matching-color PVC, applied to all exposed panel edges | |
| Desktop privacy dividers | 16mm melamine-faced particleboard, dark grey finish | |
| Drawer hardware | Cold-rolled steel three-quarter extension slides, keyed cam locks | |
| Cable management clips | ABS plastic, fixed to divider bases with pass-through slots | |
| Assembly hardware | Zinc-plated steel screws, cam locks and connecting bolts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating layout | Four individual work positions arranged back-to-back and side-by-side around central divider | |
|---|---|---|
| Central storage access | Double-sided access to lockable drawers and open shelves for adjacent users | |
| Drawer locking | Keyed locks secure each lower and upper central drawer for personal storage | |
| Desktop privacy separation | Low front-edge dividers reduce visual distraction between neighboring seats | |
| Cable management | Desk-edge cable clips route monitor and peripheral cords off the work surface | |
| Leveling adjustment | Threaded anti-slip foot caps adjust for minor floor unevenness | |
| Assembly structure | Knock-down flat-pack construction with cam-lock panel joints | |
| Surface maintenance | Stain and scratch resistant melamine finish wipes clean with standard office cleaners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Suits clustered staff seating for admin, finance or general office teams | |
|---|---|---|
| Small business workspaces | Provides dedicated storage and separation without full cubicle construction | |
| Shared co-working facilities | Assignable individual work positions with lockable personal storage | |
| Back-of-house operational zones | Durable construction for regular daily use in operational departments | |
| Call center seating zones | Low dividers reduce visual distraction while maintaining supervisor visibility |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for work surfaces | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for domestic and commercial seating-adjacent tables | |
| EN 717-1:2004 | Wood-based panel formaldehyde emission determination, E1 class verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, static load, stability and durability test requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, drawer slide and lock performance test requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applies to panel construction | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade acceptance requirement | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, desk strength and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applies to panel construction; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade acceptance requirement; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, desk strength and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
