| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions | 2400 x 1400 x 750 mm | |
|---|---|---|
| Per-user worksurface depth | 600 mm | |
| Under-desk knee clearance height | 680 mm | |
| Attached side cabinet dimensions | 1200 x 400 x 1100 mm | |
| Worksurface thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| X-leg steel tube wall thickness | 1.5 mm | |
| Cable grommet diameter | 60 mm | |
| Open upper shelf internal height | 300 mm | |
| Lower drawer unit internal height | 150 mm | |
| Center privacy screen height | 250 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worksurface static uniform load capacity | 120 kg | |
|---|---|---|
| Drawer slide cycle life | 50000 cycles | |
| Hinge cycle life for cabinet doors | 80000 cycles | |
| Total net product weight | 120 kg | |
| Maximum recommended user count | 2 persons | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface panels | E1 grade melamine-faced particle board | |
|---|---|---|
| Storage cabinet panels | Melamine-faced MDF with matte gray finish | |
| Support frame and X-legs | Powder-coated carbon steel | |
| Edge banding | 2mm thick PVC impact-resistant edging | |
| Cable management components | ABS plastic grommets and cable channels | |
| Leveling feet | Nylon adjustable floor glides | |
| Drawer hardware | Cold-rolled steel ball-bearing slides | |
| Privacy screen | Fabric-wrapped fiberboard panel | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Dual 60mm cable grommets route power and data cords to under-desk space | |
|---|---|---|
| Lockable storage drawers | Integrated key lock secures lower drawer unit for personal document storage | |
| Open upper storage shelves | Fixed open shelves hold binders and small office supplies above worksurface | |
| Dual-sided seating layout | Face-to-face worksurfaces accommodate two users at opposite sides of the desk | |
| Adjustable leveling feet | Threaded glides adjust 10mm to compensate for uneven floor surfaces | |
| Center privacy divider | Fixed mid-height screen blocks direct line of sight between seated users | |
| Reinforced X-brace frame | Angled X-leg structure reduces lateral frame sway under heavy use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office areas | Suitable for two-person team workstations in corporate open office layouts | |
|---|---|---|
| Small startup offices | Fits compact office spaces as a shared double work position with integrated storage | |
| Staff department work zones | Appropriate for admin, finance, or operations department desk arrangements | |
| Branch office standardization | Ideal for bulk procurement for multi-location office fit-outs | |
| Home office dual use | Can be used for shared home workspaces for two remote workers |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable standard for safety and strength requirements of office work tables | |
|---|---|---|
| EN 13722:2004 | Applicable standard for performance requirements of office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable performance standard for desk products used in commercial offices |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Applicable standard for formaldehyde emission limits for wood-based panel products | |
| GB/T 3327-2017 | Applicable standard for performance requirements of office desks and tables |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden office furniture; 2. GB 18580-2017: Applicable standard for formaldehyde emission limits for wood-based panel products; 3. GB/T 3327-2017: Applicable standard for performance requirements of office desks and tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
