Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2475 x 1425 x 762 mm | |
|---|---|---|
| desktop thickness | 25 mm | |
| individual per-user workspace | 1200 x 700 mm | |
| central privacy divider height | 305 mm | |
| knee clearance height under desktop | 673 mm | |
| integrated central cabinet dimensions | 1200 x 600 x 650 mm | |
| L-shaped side return surface dimensions | 1200 x 600 mm | |
| open CPU storage slot dimensions | 220 x 500 x 450 mm | |
| edge band thickness | 3 mm | |
| leg support tubing section | 60 x 30 x 1.2 mm | |
| cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 150 kg | |
|---|---|---|
| drawer slide static load per drawer | 25 kg | |
| drawer slide cycle rating | 50000 cycles | |
| cabinet hinge cycle rating | 80000 cycles | |
| surface abrasion resistance | 2000 cycles | |
| product net weight | 130 kg | |
| user capacity | 2 people | |
| warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop surface | E1-grade particleboard with light wood-grain melamine laminate | |
|---|---|---|
| cabinet body panels | Medium density fiberboard with light grey matte laminate | |
| cabinet accent panels | Matching light wood-grain melamine laminate | |
| support frame and legs | Chrome-plated 1.2mm thick steel tubing | |
| CPU compartment panels | Perforated steel mesh with powder-coated finish | |
| desktop edge banding | 3mm thick rigid PVC edging | |
| cabinet hardware | Chrome-plated steel lock cylinders and drawer pulls | |
| central privacy divider frame | Powder-coated light grey aluminum | |
| desktop divider infill | Clear frosted acrylic panel | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| face-to-face dual workstation layout | Two opposite seated positions separated by central divider | |
|---|---|---|
| integrated lockable storage | Two side lockable cabinet compartments for office supplies | |
| ventilated CPU storage | Two open perforated mesh slots under desktop for tower PCs | |
| central cable management | Grommets and under-desk cable trays route power and data cords | |
| L-shaped extended work surface | Side return desk creates additional corner workspace | |
| low-profile privacy divider | 305mm tall desktop divider blocks direct screen visibility | |
| leveling feet on storage cabinet | Adjustable glides compensate for uneven office flooring | |
| modular connection capability | Desk frames can connect to additional workstations for open plan layouts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open plan office staff areas | Two-person layout for team departments, balancing collaboration and individual focus | |
|---|---|---|
| small business startup offices | Compact L-shape fits limited floor space while providing full storage and work area | |
| co-working shared workspaces | Dual-seat configuration maximizes occupancy with independent lockable storage per user | |
| administrative and finance departments | Lockable cabinet storage supports secure document storage for daily operations | |
| executive assistant paired workstations | Face-to-face layout supports quick communication between paired staff roles | |
| hybrid work touchdown spaces | Integrated cable and CPU storage supports hot-desking for rotating in-office staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural stability validation | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables mechanical safety requirements, applicable to load and durability testing | |
| EN 13722:2004 | Furniture strength and durability for office storage units, applicable to cabinet testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to structural load and cycle testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to cabinet and drawer durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and cabinet construction | |
|---|---|---|
| GB/T 3327-2023 | Performance requirements for office desks, applicable to structural stability and load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade substrate verification | |
| GB/T 4897.3-2015 | Particleboard specification for furniture use, applicable to desktop substrate quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and cabinet construction; 2. GB/T 3327-2023: Performance requirements for office desks, applicable to structural stability and load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade substrate verification; 4. GB/T 4897.3-2015: Particleboard specification for furniture use, applicable to desktop substrate quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
