Two-Tone L-Shaped Staff Office Workstation Desk with Integrated Lockable Storage and Privacy Divider (model LWS-1412-LD2S2-75) is listed under Open Workstation, with overall dimensions of 2450 × 2100 × 1200 mm and main material of Particle‑board (PB). Load capacity: 300 kg. Certifications: Two-tone,finish,L-shaped,corner,layout,integrated,lockable,storage,desktop,privacy,divider,metal,leg,support,cable,management,channel. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled footprint | 2450 x 2100 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Main worktop depth | 700 mm | |
| Side return storage cabinet depth | 600 mm | |
| Seated knee clearance height | 620 mm | |
| Seated knee clearance width | 800 mm | |
| Desktop privacy divider height | 450 mm above worktop | |
| Privacy divider panel thickness | 40 mm | |
| Worktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Cylindrical metal leg diameter | 60 mm | |
| Open storage cubby internal height | 300 mm | |
| Cable management channel width | 100 mm | |
| Cable grommet diameter | 80 mm | |
| Adjustable chrome foot height | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worktop static load capacity | 300 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 open/close cycles | |
| Drawer lock cycle rating | 10000 lock/unlock cycles | |
| Worktop surface abrasion resistance | 2000 revolutions | |
| Unit net weight (assembled) | 115 kg | |
| Seating capacity | 1 person | |
| Leveling foot adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop and drawer fronts | 25mm E1 grade melamine-faced particle board | |
|---|---|---|
| Cabinet body and modesty panel | 18mm dark charcoal melamine-faced particle board | |
| Support legs | 60mm diameter powder-coated steel cylindrical tubes | |
| Privacy divider panel | 40mm thick fabric-wrapped fiberboard | |
| Drawer hardware | Zinc-alloy lock cores, chrome-plated steel handles, ball-bearing steel slides | |
| Cable management components | Powder-coated steel channel, ABS plastic cable grommets |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | 2 keyed lockable drawers plus 2 open middle storage cubbies | |
|---|---|---|
| Cable management | Rear top routing channel and desktop grommet for power/data cords | |
| Leveling adjustment | Chrome-plated adjustable feet on metal support legs | |
| Privacy screening | Vertical desktop divider blocks seated sightlines between adjacent workstations |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office work areas | Single-seat partitioned workstation for individual staff task work | |
|---|---|---|
| Small business and startup offices | Space-efficient L-shape fits corner layouts with integrated file storage |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial workstations | |
|---|---|---|
| EN 1335-2:2009 | Office furniture structural safety reference for desk-user interface dimensions | |
| EN 14073-2:2004 | Office storage furniture safety and durability requirements for integrated drawers |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and durability performance standard for office workstations | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated cabinet and drawer components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and cabinet construction | |
|---|---|---|
| GB/T 3327-2018 | Office furniture performance requirements for desks and storage units | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to engineered wood components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and cabinet construction; 2. GB/T 3327-2018: Office furniture performance requirements for desks and storage units; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to engineered wood components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
