PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Workstation total weight	168 kg
Desktop distributed load	60 kg
Pedestal top load	30 kg
Drawer load per drawer	15 kg
Seating capacity	4 users
Drawer slide cycle rating	50000 cycles
Caster rolling load per pedestal	45 kg
Desktop surface impact resistance	40 N drop-ball acceptance target
Surface abrasion rating	2000 cycles
Warranty duration	5 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop substrate and finish	25 mm melamine-faced particleboard with 2 mm impact-resistant PVC edge banding
Support legs	Powder-coated square steel tube, 50 x 50 mm with 1.5 mm wall thickness
Drawer pedestals	18 mm melamine-faced particleboard carcass with matching light wood drawer fronts and gray side panels
Privacy screens	Fabric-wrapped acoustic panel over a rigid composite board, 30 mm thick
Drawer hardware	Side-mounted ball-bearing drawer slides with four twin-wheel swivel casters per pedestal
Cable and socket plates	Gray plastic or aluminum access plates with socket inserts and desk grommets

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Individual work zones	Four separate 1200 x 600 mm desks arranged face-to-face in a 2 x 2 cluster with divider screens between users.
Storage operation	Each user position has a three-drawer mobile pedestal with two shallow utility drawers and one deeper file drawer.
Mobility and positioning	Pedestals use four swivel casters and can be moved under the desk or used as a partial side support during reconfiguration.
Cable management	Desktop grommets and side access plates route monitor and power cables from the work surface toward pedestal-mounted sockets.

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office use	Suited to four-person team clusters in open offices because divider screens provide visual separation while retaining compact circulation.
Administrative and knowledge-work settings	Appropriate for computer-based tasks, paperwork and supervised teams due to individual 1200 mm surfaces and drawer-level personal storage.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1 office desks	Use for office desk safety, dimensional and structural design requirements
EN 527-2 test methods	Use for desk strength, durability and stability verification
EN 1022 stability test basis	Use for seating-area furniture stability assessment of the complete workstation layout
EN 13986 wood-based panels	Use for panel performance classification and declaration of board substrate properties
EN 71-3 surface material migration	Use only if low-risk surface material testing is required for accessible finishes

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5 desk products	Use for load, cycle, drop and stability testing of office desk structures
ANSI/BIFMA X5.9 storage units	Use for strength, durability and stability testing of mobile drawer pedestals
ANSI/BIFMA e3 sustainability credits	Use when requesting material, energy, social responsibility and EPD-related documentation
ANSI/BIFMA X5.4 seating-side storage interface	Use for lounge or seating interface checks only where pedestals are used adjacent to mobile chairs

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324 acceptance basis	Use for dimensional tolerance, material, construction and finish inspection of wooden office furniture
GB/T 3325 metal furniture inspection	Use for strength, coating and structural inspection of steel table supports
GB/T 11460 seating and workstation layout	Use as a reference for office desk height, seating clearance and ergonomic arrangement
GB 18584 indoor furniture limit	Use as the procurement emission and indoor-air limit requirement for board furniture
GB/T 29608 plastic components	Use where plastic grommets, caster bodies and socket covers are specified

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324 acceptance basis: Use for dimensional tolerance, material, construction and finish inspection of wooden office furniture;
2. GB/T 3325 metal furniture inspection: Use for strength, coating and structural inspection of steel table supports;
3. GB/T 11460 seating and workstation layout: Use as a reference for office desk height, seating clearance and ergonomic arrangement;
4. GB 18584 indoor furniture limit: Use as the procurement emission and indoor-air limit requirement for board furniture;
5. GB/T 29608 plastic components: Use where plastic grommets, caster bodies and socket covers are specified;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-4P-1200X600-PED

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-4P-1200X600-PED

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-4P-1200X600-PEDOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Four-Person Panel-Based Office Workstation is an unbranded cluster desk system designed for teams that require defined personal work areas, integrated storage, and a compact open-plan layout. Its model, WS-4P-1200X600-PED, arranges four individual 1200 x 600 mm desks face-to-face in a 2 by 2 configuration, with fabric-covered divider screens positioned between users. The screens introduce visual separation and a softened, layered appearance while preserving the orderly footprint of a shared workstation cluster. Each work zone is paired with a three-drawer mobile pedestal, finished with light wood drawer fronts and gray side panels. The pedestals can be placed beneath the desk for direct personal storage or repositioned as partial side support when the layout changes. Two shallow utility drawers and one deeper file drawer provide practical separation for stationery, documents, and personal work materials. Side-mounted ball-bearing drawer slides support regular daily use, while four twin-wheel swivel casters allow the pedestal to be moved without relocating the main workstation. The work surface is built from melamine-faced particleboard with impact-resistant PVC edge banding. The desktop substrate is 25 mm thick, with a finished top thickness of 50 mm in the assembled configuration. Square powder-coated steel legs provide the primary support structure, combining a clean metal frame with the durable melamine surfaces. The divider panels use fabric-wrapped acoustic material over a rigid composite board and are 30 mm thick, giving the workstation a contemporary panel-based aesthetic suitable for modern office interiors. Cable management is integrated through desk grommets and side access plates. Monitor and power cables can be routed from the work surface toward pedestal-mounted sockets, helping reduce cable clutter across the desktop. Gray plastic or aluminum access plates, socket inserts, and an 80 mm cable opening support organized connections for computer-based work. The cable tray has a depth of 120 mm, and each main seat position provides 680 mm high and 900 mm wide effective knee clearance. This workstation is well suited to open-plan offices, administrative teams, paperwork roles, supervised workgroups, and other knowledge-work environments where four users need coordinated but individually defined spaces. It is also appropriate for residential workrooms or large home offices used by multiple people, provided the floor area can accommodate the cluster and circulation space around the pedestals. Procurement planning should account for the multi-piece structure, mobile storage units, need for assembly, and total finished weight. The system is rated for four users, with a desktop distributed load of 60 kg, pedestal top load of 30 kg, and 15 kg load capacity per drawer. Buyers should also confirm delivery access, floor protection for casters, available power positions, and whether the visual privacy level matches the intended workplace culture.
