Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1400 x 750 mm | |
|---|---|---|
| Single individual workstation size | 1400 x 700 mm | |
| Privacy divider height above desktop | 350 mm | |
| Under-desk knee clearance height | 650 mm | |
| Knee clearance depth per seat | 500 mm | |
| Central storage pedestal dimensions | 420 x 460 x 650 mm | |
| Table leg splay angle from vertical | 12 degrees | |
| Desktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel frame wall thickness | 1.5 mm | |
| Privacy divider panel thickness | 40 mm | |
| Drawer interior usable height | 150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 130 kg | |
|---|---|---|
| Per-workstation static desktop load capacity | 80 kg | |
| Recommended number of users | 4 | |
| Surface abrasion resistance | 2000 cycles | |
| Formaldehyde emission level | 0.05 mg/m³ | |
| Standard commercial warranty period | 5 years | |
| Available finish color options | 60 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | 25mm E1 grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Privacy dividers | 40mm thick fabric-covered MDF core in sage green matte finish | |
| Table leg frame | 1.5mm thick powder-coated white steel with angled splayed design | |
| Drawer fronts | 18mm MDF with sage green matte powder coating, fitted with black metal pull handles | |
| Storage pedestal body | 18mm melamine-faced particleboard matching desktop finish | |
| Drawer slides | Three-section full-extension cold-rolled steel ball-bearing slides | |
| Desk leveling feet | Nylon height-adjustable feet fitted to table leg bases | |
| Cabinet casters | 360-degree swivel nylon casters on central pedestal base | |
| Cable management grommets | ABS plastic double-layer cable ports with removable covers | |
| Connecting hardware | Zinc-plated steel three-in-one cam lock connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Modular layout configuration | Supports linear expansion to 6, 8, or more connected workstations | |
|---|---|---|
| Central storage function | Mobile pedestal with two lockable drawers and two open storage cubbies | |
| Cable management | Dual desktop cable grommets route power and data cables under work surface | |
| Privacy separation | Desk-mounted dividers block direct line of sight between facing seated users | |
| Height adjustment | ±10mm adjustable leveling feet compensate for uneven carpet or hard flooring | |
| Drawer operation | Full-extension soft-close drawers open fully to access back of storage space | |
| Surface maintenance | Stain-resistant, scratch-resistant melamine finish wipes clean with standard office cleaners | |
| Pedestal mobility | Lockable swivel casters allow central cabinet to reposition between workstation pairs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Suitable for corporate open office zones supporting collaborative and individual staff work | |
|---|---|---|
| Co-working shared spaces | Adaptable for flexible co-working environments with adjustable modular layout | |
| Startup and SME office floors | Cost-effective modular solution for growing teams with easy staff count expansion | |
| Government and institutional offices | Meets standard procurement durability and emission requirements for public sector use | |
| Call center and administrative floors | Provides individual privacy and accessible storage for high-density staff seating | |
| Project-based team zones | Configurable for cross-functional team clusters with shared central storage access |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial workstations | |
|---|---|---|
| EN 13986:2004+A1:2015 | Wood-based panels for construction, formaldehyde emission and structural performance | |
| EN 15372:2016 | Office furniture storage units, durability and strength for pedestal drawer units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applies to load capacity and durability testing of work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applies to drawer durability and load rating for central pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel structural performance | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables, applies to dimensional and stability requirements for workstations | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture use | |
| GB/T 4897-2015 | Particleboard specification, applicable to core material of desk worktops and cabinet body |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel structural performance; 2. GB/T 3327-2016: Office desks and tables, applies to dimensional and stability requirements for workstations; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture use; 4. GB/T 4897-2015: Particleboard specification, applicable to core material of desk worktops and cabinet body; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
