6-Person Back-to-Back Open Office Workstation Desk with Dividers and Locking Drawer Pedestals (model WS-6P-BB-LW1400) is listed under Open Workstation, with overall dimensions of 4200 × 1400 × 1100 mm and main material of Particle‑board (PB). Load capacity: 80 kg. Certifications: Modern,style,modular,bench,structure,back-to-back,6-seat,layout,under-desk,locking,storage,desktop,privacy,dividers. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cluster dimensions | 4200 x 1400 x 1100 mm | |
|---|---|---|
| Desktop working height | 750 mm | |
| Per-seat work surface width | 1400 mm | |
| Per-side desktop depth | 700 mm | |
| Privacy divider height above desktop | 350 mm | |
| Suspended pedestal dimensions | 412 x 588 x 500 mm | |
| Knee clearance height under desktop | 620 mm | |
| Knee clearance depth per seat | 450 mm | |
| Desktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel square leg section size | 50 x 50 mm | |
| Steel frame wall thickness | 1.8 mm | |
| Cable grommet diameter | 80 mm | |
| Leveling glide adjustable height | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Evenly distributed desktop static load per seat | 80 kg | |
|---|---|---|
| Per drawer static load capacity | 30 kg | |
| Total workstation net weight | 280 kg | |
| Recommended user weight capacity per position | 150 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Lock mechanism cycle rating | 10000 cycles | |
| Surface scratch resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate and finish | E1 grade particleboard core, light oak melamine thermally fused laminate, 2mm PVC edge banding | |
|---|---|---|
| Frame and leg structure | Powder-coated matte white square steel tubing with horizontal cross-bracing, anti-slip nylon leveling glides | |
| Privacy dividers | Gray fabric-wrapped acoustic fiberboard panels with steel mounting brackets | |
| Drawer pedestals | Two-tone light wood and gray steel drawer boxes, keyed cam lock on top drawer, three-section ball-bearing slides | |
| Hardware components | Zinc-plated steel connecting bolts, lock cylinders, and mounting clips for modular assembly | |
| Cable management | ABS plastic cable grommets and under-desk steel wire tray with 15kg load capacity |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular layout configuration | 3 seats per opposing row arranged in linear back-to-back bench, expandable with matching connecting modules | |
|---|---|---|
| Privacy screening | Upright fabric dividers block direct sightlines between opposite seated workers for focused work | |
| Secured personal storage | Each position includes a suspended 2-drawer pedestal with keyed lock for personal document and supply storage | |
| Cable routing | Desktop grommets and under-desk tray route power and data cables from floor to work surface, eliminating cord clutter |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff work areas | Accommodates 6 seated employees in space-efficient linear layout for general administrative or call center tasks | |
|---|---|---|
| Startup and co-working flexible spaces | Modular design allows reconfiguration to match changing team sizes and office layout needs |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 Office furniture - Work tables and desks - Part 1: Dimensions | Defines required seated work surface height, clearance, and dimensional tolerances for office desk workstations | |
|---|---|---|
| EN 527-2:2016 Office furniture - Work tables and desks - Part 2: Mechanical safety requirements | Specifies structural stability, static load, and fatigue test requirements for commercial office desks | |
| EN 1335-2:2009 Office furniture - Office work chair - Part 2: Safety requirements | Referenced for compatible dimensional clearance between desk and standard task chair dimensions |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 Desk Products - Tests | Defines industry-standard static load, impact, and cycle tests for commercial desk and pedestal performance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to desktop panel dimensional stability, edge bonding strength, and surface finish durability for office wooden furniture | |
|---|---|---|
| GB/T 3325-2017 General technical requirements for metal furniture | Applies to steel frame welding quality, powder coating adhesion, and structural load capacity for metal furniture components | |
| GB 18580-2017 Indoor decorating and refurbishing materials - Formaldehyde emission limits for wood-based panels | Specifies E1 grade ≤0.124mg/m³ formaldehyde emission limit for all engineered wood panels used in indoor office furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to desktop panel dimensional stability, edge bonding strength, and surface finish durability for office wooden furniture; 2. GB/T 3325-2017 General technical requirements for metal furniture: Applies to steel frame welding quality, powder coating adhesion, and structural load capacity for metal furniture components; 3. GB 18580-2017 Indoor decorating and refurbishing materials - Formaldehyde emission limits for wood-based panels: Specifies E1 grade ≤0.124mg/m³ formaldehyde emission limit for all engineered wood panels used in indoor office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
