Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk + return) | 1600 x 1600 x 760 mm | |
|---|---|---|
| Main worktop depth | 600 mm | |
| Side storage return width | 750 mm | |
| Tabletop thickness | 25 mm | |
| Desktop divider height above worktop | 300 mm | |
| Knee clearance height under worktop | 650 mm | |
| Knee clearance width between return and leg | 800 mm | |
| Open CPU bay internal dimensions | 240 x 500 x 480 mm | |
| Drawer front panel thickness | 18 mm | |
| A-frame leg tubing wall thickness | 1.5 mm | |
| ABS edge banding thickness | 2 mm | |
| Adjustable foot pad height adjustment range | 10 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Worktop static uniform load capacity | 91 kg | |
|---|---|---|
| Recommended maximum user weight for desk use | 136 kg | |
| Frame and structure limited warranty | 5 years | |
| Surface abrasion resistance | 2000 cycles | |
| Product net weight | 52 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop | 25mm E1 grade engineered wood with melamine facing, 2mm ABS edge banding | |
|---|---|---|
| Side storage cabinet body | 18mm E1 grade engineered wood with matching white melamine finish | |
| Desktop privacy divider | 18mm solid MDF panel with warm brown matte finish | |
| Right support leg | 1.5mm thick powder-coated light gray steel A-frame structure, brown plastic joint accent | |
| Drawer slides | Cold-rolled steel ball-bearing three-section full-extension slides | |
| Drawer hardware | Zinc alloy lock core on top drawer, matching brown horizontal pull trim | |
| Leveling feet | Reinforced nylon adjustable foot pads with non-slip rubber base | |
| Divider mounting clips | Injection-molded orange ABS plastic brackets securing divider to worktop | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Drawer storage configuration | One lockable top supply drawer, one lower general storage drawer, one open CPU bay | |
|---|---|---|
| Top drawer locking function | Keyed lock secures top drawer to protect confidential documents and valuables | |
| Cable management | 60mm cable grommet on worktop routes power and data cables below the surface | |
| Leveling adjustment | Adjustable foot pads compensate for uneven floors to keep worktop perfectly level | |
| Divider function | Low back divider provides partial visual privacy without blocking overhead light | |
| Drawer operation | Ball-bearing slides allow smooth full-extension drawer access without jamming | |
| Surface maintenance | Stain and scratch-resistant melamine finish wipes clean with standard office cleaning products | |
| Storage return support | Left storage cabinet acts as a structural support for the L-shaped worktop | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff workstations | Fits single-seat layouts with low divider for partial visual privacy between users | |
|---|---|---|
| Home office computer workspaces | Compact L-shape fits small home rooms with dedicated CPU and supply storage | |
| Small startup team work areas | Cost-effective standalone desk for individual employee work positions | |
| Freelancer work studios | Provides separate work surface and storage for office supplies and computer equipment | |
| Recommeded pairing | Pairs with standard mid-back office chairs with 520 mm adjustable seat height | |
| Placement recommendation | Position against wall or cubicle row to maximize floor space efficiency | |
| Suitable equipment load | Supports single monitor, laptop, keyboard and desktop computer tower without overloading |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, reference for structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety requirements, reference for clearance dimensions | |
| EN 13722:2004 | Furniture storage units strength and durability requirements, applicable to drawer cabinet |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, reference for load and cycle testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural integrity | |
|---|---|---|
| GB/T 3327-2016 | Performance test method for office desks and tables, applicable to load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural integrity; 2. GB/T 3327-2016: Performance test method for office desks and tables, applicable to load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
