Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main worktop + side return) | 1800 x 1600 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 150 kg | |
|---|---|---|
| Drawer unit static load per drawer | 25 kg | |
| Product net weight per single desk | 115 kg | |
| Recommended maximum user weight per workstation | 120 kg | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Structure service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 25mm thick E1 grade particleboard with matte melamine laminate finish | |
|---|---|---|
| Support frame and legs | 1.5mm thick powder-coated dark green square steel tubing | |
| Desktop divider | 18mm thick particleboard core upholstered in reddish-brown anti-glare fabric | |
| Storage pedestal and cabinet panels | 18mm thick E1 grade particleboard with matte powder-coat effect melamine finish | |
| Storage hutch shelves | 15mm thick melamine-faced particleboard | |
| Drawer hardware | Cold-rolled steel drawer slides with integrated lock on top drawer | |
| Leveling feet | Nylon-tipped adjustable steel glides on storage unit base | |
| Cable management port | ABS plastic grommet fitted at worktop center | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Centered worktop grommet routes power and data cables below the work surface | |
|---|---|---|
| Workspace division | Upholstered desktop divider creates visual separation between adjacent facing workstations | |
| Fixed height worktop | Worktop set at 750mm universal office working height, no height adjustment mechanism | |
| Pedestal mobility | Storage pedestal fixed to desk frame with no casters, supported by adjustable leveling feet | |
| Hutch storage access | Open hutch shelves accessible from the seated work position for frequently used documents | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office workstations | Suitable for clustered employee work zones with integrated storage to reduce clutter | |
|---|---|---|
| Executive private offices | Configurable as a single standalone desk with full storage for managerial staff | |
| Small business administrative areas | Ideal for reception or admin teams requiring accessible filing and work space | |
| Co-working dedicated desks | Suitable for fixed assigned seats in co-working facilities with personal lockable storage | |
| Home office premium setups | Appropriate for dedicated home workspaces requiring professional storage capacity |
EU Market Access Requirements* EN Standards
| Office desk safety and strength requirement | EN 527:2002+A1:2019 | |
|---|---|---|
| Office furniture stability requirement | EN 14073:2004 |
US and Canada office-furniture standards
| Desk performance standard | ANSI/BIFMA X2021 |
|---|
Standards applicable to China-market projects
| Desk dimensional and safety requirement | GB/T 3326 | |
|---|---|---|
| Desk surface durability requirement | GB/T 4897.3 | |
| Formaldehyde emission limit | GB 18580 |
This product must meet the following technical requirements: 1. Desk dimensional and safety requirement: GB/T 3326; 2. Desk surface durability requirement: GB/T 4897.3; 3. Formaldehyde emission limit: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
