PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2800 × 1400 × 750 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Overall product weight	185 kg
Distributed desktop static load	120 kg
Single drawer static load	25 kg
Maximum user count	4
Frame lateral stability load	80 kg
Adjustable foot maximum level adjustment	10 mm
Recommended product service life	8 years
Standard warranty period	3 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop substrate	18mm high-density particleboard, 25mm total thickness
Desktop finish	Maple-pattern melamine laminate
Frame and leg material	1.5mm thick Q235 steel tube, dark green powder coating
Privacy divider padding	25mm high-resilience polyurethane foam
Divider upholstery	Polyester woven fabric, brown color
Pedestal carcass	18mm melamine-faced particleboard, dark gray and maple finish
Drawer slides	Three-section ball-bearing steel slides
Edge banding	2mm thick ABS edge trim
Leveling feet	Reinforced nylon with steel threaded insert
Cable grommet cover	Matte black ABS plastic
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Cable management grommets	Each of 4 positions has an 80mm grommet
Central lock system	Key lock secures top and bottom drawer sets
Adjustable floor leveling	Threaded feet adjust up to 10mm
Modular construction	Desk splits into 4 tabletop sections for flat-pack shipping
Privacy screen mounting	Screens are fixed to desktop center with metal brackets
Full-extension drawer access	Drawers extend 100% to access rear stored items
Modesty panel screening	Central steel panel blocks line of sight to opposite users' legs
Anti-scratch foot protection	Nylon foot caps prevent hard floor damage
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office areas	Supports 4 users in shared team work zones
Co-working flexible spaces	Standard dimensions fit co-working open seating plans
Corporate back-office areas	Ideal for finance, HR and operations workstations
Startup open offices	Cost-effective 4-seat configuration for growing teams

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables: Safety and strength requirements
EN 527-2:2002+A1:2019	Office work tables: Safety and dimensional requirements
EN 13986:2004+A1:2015	Wood-based panels for construction use

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture
GB/T 3327-2016	Performance requirements for office desks
GB 18580-2017	Formaldehyde emission limits for wood-based panels

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture;
2. GB/T 3327-2016: Performance requirements for office desks;
3. GB 18580-2017: Formaldehyde emission limits for wood-based panels;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-4P-CEN-MAP-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-4P-CEN-MAP-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-4P-CEN-MAP-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The 4-Person Open Office Workstation with Central Pedestal and Dividers (model WS-4P-CEN-MAP-01) is an unbranded office workstation desk designed to support efficient shared work in open environments. Its layout organizes four dedicated work positions around a central integrated pedestal, with upholstered privacy dividers fixed to the desktop center via metal brackets to define individual work zones without fully blocking team interaction. A central steel modesty panel sits between opposite seats to block direct line of sight to users’ legs, balancing openness and personal comfort. The worktop features a warm maple-pattern melamine laminate finish, paired with a dark green powder-coated steel frame and brown fabric-covered dividers, creating a muted, professional aesthetic that blends with most modern interior palettes. Constructed for regular commercial use, the workstation uses durable, practical materials: desktops are built with high-density particleboard substrates faced with melamine, finished with thick ABS edge banding to resist impact damage at high-wear edges. The frame uses Q235 steel tubing, with reinforced nylon leveling feet fitted with steel threaded inserts to accommodate uneven floors. The central pedestal is made from melamine-faced particleboard in complementary dark gray and maple finishes, with drawers running on three-section ball-bearing steel slides that allow full extension for easy access to stored items at the rear of each drawer. Privacy dividers are padded with high-resilience polyurethane foam for soft, tactile surface quality. Functional features are tailored to daily office use: each work position includes a cable management grommet, paired with an integrated cable tray to route power and data cords neatly off the work surface. A central key lock system secures both top and bottom drawer sets to protect stored personal or work materials, while the modular design splits into individual tabletop sections for flat-pack shipping. The unit supports a distributed desktop static load suited for standard office equipment, with individual drawer load ratings aligned to regular storage of stationery, files and personal items. Recommended service life for the product is 8 years with proper use. This workstation is well suited for open-plan corporate team zones, co-working flexible seating areas, back-office departments including finance, HR and operations, and cost-conscious startup offices expanding their open workspaces. For procurement, note that the product ships in multiple cartons, with a reference assembly time of 40 minutes per set, allowing facilities teams to plan for on-site setup and receiving space appropriately. The standard footprint fits conventional open seating plans without custom modification, and the configuration eliminates the need to purchase separate individual desks and storage units for four team members.

4-Person Open Office Workstation with Central Pedestal and Dividers Specifications
