Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1200 x 1140 mm | |
|---|---|---|
| Worksurface height | 750 mm | |
| Per-user worksurface width | 1400 mm | |
| Per-user worksurface depth | 600 mm | |
| Under-desk knee clearance height | 650 mm | |
| Under-desk knee clearance depth | 450 mm | |
| Central privacy divider dimensions | 1200 x 60 x 390 mm | |
| Attached storage pedestal dimensions | 1200 x 600 x 600 mm | |
| Worktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel leg section dimensions | 50 x 20 mm | |
| Cable grommet diameter | 80 mm | |
| Drawer internal usable dimensions | 450 x 500 x 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Total product net weight | 170 kg | |
|---|---|---|
| Worksurface static distributed load capacity | 91 kg | |
| Cable tray supported static load | 5 kg | |
| Recommended number of simultaneous users | 2 | |
| Surface abrasion resistance rating | 2000 cycles | |
| Leveler adjustment range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface substrate | E0-grade melamine-faced particle board | |
|---|---|---|
| Worksurface edge finish | 2mm thick PVC edge banding | |
| Support legs | 1.5mm thick powder-coated black steel | |
| Privacy divider panel | Fabric-wrapped 60mm thick fiberboard core | |
| Storage pedestal carcass | 18mm thick melamine-faced engineered wood | |
| Pedestal drawer front | 18mm thick melamine panel with silver metal label holder and lock | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Hardware fasteners | Zinc-plated steel connector bolts and cam locks | |
| Pedestal support feet | 1.2mm thick powder-coated steel angled feet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Central privacy divider | Fabric screen mounted to worktop provides visual separation between two users | |
|---|---|---|
| Cable management access | 80mm diameter grommet near divider routes power and data cables to floor | |
| Lockable storage pedestal | Integrated fixed cabinet provides one lockable drawer and one enclosed storage compartment | |
| Floor leveling adjustment | Adjustable feet on all leg and pedestal bases correct for uneven office floors | |
| Seated ergonomic access | 650mm high knee clearance allows unobstructed seated use with standard office chairs | |
| Two-tone scratch-resistant finish | Melamine surface resists daily scuffs, spills and staining from regular office use | |
| Modular configuration compatibility | Desk clusters can be connected in longer runs for open-plan office layouts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff work areas | Dual workstation fits open plan layouts with balanced privacy and collaboration | |
|---|---|---|
| Small business team work zones | Compact two-user setup provides dedicated work and storage space for small teams | |
| Co-working space dedicated hot desks | Durable commercial construction supports regular high-turnover use in shared offices | |
| Home office dual-workspace setups | Integrated storage and divider supports two people working from one shared space | |
| Startup open office environments | Modular cluster design supports easy expansion as team headcount grows | |
| Administrative and back-office work zones | Lockable storage secures personal documents and office supplies for admin staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to commercial office workstations | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional, safety and strength requirements for work surfaces | |
| EN 1335-2:2018 | Office furniture work chairs safety requirements for compatibility with desk clearances |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for storage units, applicable to integrated pedestal cabinet performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worksurface and cabinet panels | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for metal furniture, applicable to steel legs and frame components | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to structural stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worksurface and cabinet panels; 2. GB/T 3327-2016: Technical requirements for metal furniture, applicable to steel legs and frame components; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to structural stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
