Four-Person Back-to-Back Modular Workstation with Central Dividers and Cable Trough (model WS-4P-B2B-2400-1200) is listed under Open Workstation. Dimensions: 2400 × 1200 × 1100 mm. Materials: 25 mm wood-composite substrate with white melamine or laminate facing and sealed edge banding. Load capacity: 45 kg per seat. Product Features: White,and,grey,finish,four-seat,layout,back-to-back,partition,cable,management,splayed,metal,legs,fixed-height,workstation. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | GENUOWA | Model | WS-4P-B2B-2400-1200 |
| Finished Top Thickness | 50 mm | Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
| Workstation capacity | 4 users | Distributed desktop load | 45 kg per seat |
| Central divider panel load | 5 kg lateral pressure | Complete cluster net weight | 96 kg |
| Recommended floor live load | 2.5 kN/m2 | Cable route capacity per side | 2 power cables and 4 data cables |
| Leveling adjustment per glide | 10 mm | Suggested procurement warranty | 5 years |
| Available colorway count | 2 colors | Top Static Load Reference | 150 kg uniformly distributed |
| Work surface construction | 25 mm wood-composite substrate with white melamine or laminate facing and sealed edge banding | Central divider | Rigid composite core upholstered in grey woven fabric with a vertical rectangular insert |
| Metal frame and end supports | Grey powder-coated steel tube and sheet-steel end cabinets with visible fastener points | Exposed desk legs | White round steel tube splayed legs with grey protective floor glides |
| Modesty panels | White rigid vertical panels attached below the rear desktop edge | Cable management components | Grey central steel or PVC trough cover with circular black plastic cable grommets |
| Four-person back-to-back seating | Two workstations face outward on each long side, sharing one central service spine and divider row | Central cable routing | Power and data cables run in the grey spine and pass through 60 mm desktop grommets to each user position |
| Privacy separation | Two upright fabric screens provide 350 mm-high visual separation between opposite users while leaving overhead communication open | Fixed-height installation | The desks use rigid leg-and-end-panel supports at 750 mm working height rather than electric or crank height adjustment |
| Total gross weight | 110 kg | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | Reference Packaging Volume | 1 m³/set |
| Open-plan office seating | Suitable for four staff in compact open offices where shared cable routing and low visual separation are required | Call center or administrative area | Appropriate for high-density task seating because each user receives a 1200 x 600 mm work surface and an independent cable grommet |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Workstation capacity | 4 users | |
|---|---|---|
| Distributed desktop load | 45 kg per seat | |
| Central divider panel load | 5 kg lateral pressure | |
| Complete cluster net weight | 96 kg | |
| Recommended floor live load | 2.5 kN/m2 | |
| Cable route capacity per side | 2 power cables and 4 data cables | |
| Leveling adjustment per glide | 10 mm | |
| Suggested procurement warranty | 5 years | |
| Available colorway count | 2 colors | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface construction | 25 mm wood-composite substrate with white melamine or laminate facing and sealed edge banding | |
|---|---|---|
| Central divider | Rigid composite core upholstered in grey woven fabric with a vertical rectangular insert | |
| Metal frame and end supports | Grey powder-coated steel tube and sheet-steel end cabinets with visible fastener points | |
| Exposed desk legs | White round steel tube splayed legs with grey protective floor glides | |
| Modesty panels | White rigid vertical panels attached below the rear desktop edge | |
| Cable management components | Grey central steel or PVC trough cover with circular black plastic cable grommets |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Four-person back-to-back seating | Two workstations face outward on each long side, sharing one central service spine and divider row | |
|---|---|---|
| Central cable routing | Power and data cables run in the grey spine and pass through 60 mm desktop grommets to each user position | |
| Privacy separation | Two upright fabric screens provide 350 mm-high visual separation between opposite users while leaving overhead communication open | |
| Fixed-height installation | The desks use rigid leg-and-end-panel supports at 750 mm working height rather than electric or crank height adjustment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total gross weight | 110 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office seating | Suitable for four staff in compact open offices where shared cable routing and low visual separation are required | |
|---|---|---|
| Call center or administrative area | Appropriate for high-density task seating because each user receives a 1200 x 600 mm work surface and an independent cable grommet |
EU Market Access Requirements* EN Standards
| Office desk safety and stability | EN 527:2011 should govern safety, dimensions and static stability for non-domestic office desks | |
|---|---|---|
| Office desk mechanical durability | EN 527:2002 should be used for strength, durability and stability testing of the desktop, legs and end supports | |
| Office workstation ergonomics | EN 527working-height and leg-clearance provisions support the fixed 750 mm seated-desk configuration | |
| Fabric fire behavior | BS EN 1021:2014 should be specified for cigarette ignition resistance of the divider upholstery when required by the project |
US and Canada office-furniture standards
| Desk strength and fatigue reference | ANSI/BIFMA X2021can be specified for desk static load, leg strength, drawer-equivalent support and fatigue acceptance where applicable | |
|---|---|---|
| Panel furniture emissions reference | ANSI/BIFMA e2019e can be used for furniture sustainability, emissions and material documentation if the project requires BIFMA reporting |
Standards applicable to China-market projects
| Desktop structural suitability | GB/T 3324dimensions and structural performance requirements for wooden furniture should be used for desk-top load and stability acceptance | |
|---|---|---|
| Formaldehyde verification | GB/T 39600E1 limits should be specified for any wood-composite panels used in the desktop and modesty panels | |
| Safety edge and stability check | GB 28007 may be used as a children's-furniture safety reference only when the workstation is supplied for school or under-18 use |
This product must meet the following technical requirements: 1. Desktop structural suitability: GB/T 3324dimensions and structural performance requirements for wooden furniture should be used for desk-top load and stability acceptance; 2. Formaldehyde verification: GB/T 39600E1 limits should be specified for any wood-composite panels used in the desktop and modesty panels; 3. Safety edge and stability check: GB 28007 may be used as a children's-furniture safety reference only when the workstation is supplied for school or under-18 use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
