| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 700 x 1200 mm | |
|---|---|---|
| Main work surface height | 750 mm | |
| Per-seat work surface width | 1200 mm | |
| Desktop panel thickness | 18 mm | |
| Desktop edge band thickness | 2 mm | |
| Central privacy divider height | 300 mm | |
| Elevated rear hutch shelf height above desktop | 250 mm | |
| Right storage pedestal width | 500 mm | |
| Vented CPU compartment internal dimensions | 600 x 230 x 456 mm | |
| Knee clearance height under left workstation | 680 mm | |
| Knee clearance depth under left workstation | 600 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Hairpin leg rod diameter | 12 mm | |
| Drawer internal usable depth | 450 mm | |
| Adjustable foot pad height adjustment range | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total desktop static load capacity | 159 kg | |
|---|---|---|
| Product net weight | 110 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Drawer slide cycle rating | 50000 cycles | |
| Maximum supported user count | 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface and cabinet panels | 18mm E1-grade engineered wood with white-washed gray laminate finish | |
|---|---|---|
| Leg frame and cross bracing | Powder-coated matte black steel hairpin legs with X-shaped cross support | |
| Central privacy divider | Diamond-pattern expanded steel mesh with black powder coating | |
| Drawer and cabinet door fronts | Matte dark gray powder-coated MDF panels | |
| CPU compartment vents | Perforated matte gray steel vent grilles | |
| Cabinet foot pads | Injection-molded nylon adjustable leveling glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Recessed desktop cable port routes cords to under-desk space | |
|---|---|---|
| CPU storage | Two vented under-desk compartments accommodate full-size ATX towers | |
| Drawer storage | Two pedestal drawers include lockable top drawer for valuables | |
| Elevated hutch storage | Open rear raised shelf provides off-desktop storage for supplies |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff work areas | Dual adjacent layout supports two employees with built-in personal privacy divider | |
|---|---|---|
| Small startup and co-working spaces | Integrated storage and cable management reduces need for additional furniture |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for commercial office use | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for non-domestic seating/work surfaces | |
| EN 13722:2004 | Office furniture storage units performance requirements for pedestal drawers |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer cycle and load performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel construction | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and legs | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade requirement for panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel construction; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and legs; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade requirement for panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
