4-Person Back-to-Back Office Workstation Desk with Orange Privacy Dividers and Lockable Two-Drawer Pedestals (model OFW-BB4-OR-2P2800) is listed under Open Workstation, with overall dimensions of 2800 × 1200 × 750 mm and main material of Particle‑board (PB). Load capacity: 318 kg. Certifications: Open-plan,benching,integrated,storage,low,privacy,dividers,cable,management,grommets. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2800 x 1200 x 750 mm | |
|---|---|---|
| Single user worktop size | 1200 x 600 mm | |
| Worktop thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Privacy divider height | 350 mm | |
| Privacy divider thickness | 18 mm | |
| Knee clearance height under desk | 673 mm | |
| Knee clearance width per position | 1100 mm | |
| Cable grommet diameter | 60 mm | |
| Fixed two-drawer pedestal size | 400 x 550 x 700 mm | |
| Drawer internal depth | 500 mm | |
| Support leg section size | 50 x 50 mm | |
| Steel leg wall thickness | 1.5 mm | |
| Drawer front panel thickness | 18 mm | |
| Modular connection bracket size | 100 x 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total desktop static load capacity | 318 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Surface scratch resistance | 2 Class | |
| Pedestal lock key differ count | 200 | |
| Adjustable leveling foot adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop core and surface | E1 grade particleboard core with thermally fused white melamine finish | |
|---|---|---|
| Support frame and legs | Powder-coated black matte steel angled legs with welded cross supports | |
| Privacy dividers | Curved orange melamine-faced MFC panels with notched bottom edge | |
| Storage pedestals | Two-tone black and white laminated particleboard cabinet with light wood grain pull handles | |
| Hardware components | Zinc-plated steel screws, cam locks, three-section ball-bearing drawer slides | |
| Cable management parts | Black ABS plastic desktop grommets with removable brush inserts |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Each work position has a desktop grommet paired with under-desk cable routing to organize power and data cords | |
|---|---|---|
| Storage security | Each two-drawer pedestal has a central key lock to secure both drawer compartments | |
| Privacy screening | Low curved dividers block direct sightlines between facing seated users without blocking upper office visibility | |
| Modular expansion | Steel connecting brackets allow linking additional back-to-back desk runs for larger open-plan team layouts |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office staff areas | Designed for team departments and general administrative staff in shared work zones | |
|---|---|---|
| Financial and administrative departments | Integrated lockable pedestals support secure file storage for paperwork-heavy roles |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office worktables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-3:2003 | Office worktables test methods for stability and mechanical strength | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to pedestal cabinets | |
| EN 14073-3:2004 | Office storage furniture stability and strength test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for pedestal drawer performance and lock function | |
| ANSI/BIFMA M7.1-2019 | Standard test methods for furniture VOC emissions for indoor office use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktops and cabinet components | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks, applicable to structural load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to particleboard/MFC components | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to static load and durability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktops and cabinet components; 2. GB/T 3327-2016: Performance test methods for office desks, applicable to structural load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to particleboard/MFC components; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to static load and durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
