Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 1200 x 750 mm | |
|---|---|---|
| Individual work surface depth per user | 600 mm | |
| Central desktop divider height | 350 mm | |
| Rear modesty/utility panel height | 300 mm | |
| Under-desk seated knee clearance height | 673 mm | |
| Cable management grommet diameter | 60 mm | |
| Side storage pedestal dimensions | 400 x 600 x 654 mm | |
| Steel support leg cross-section | 50 x 50 mm | |
| Worktop panel thickness | 38 mm | |
| Edge banding thickness | 2 mm | |
| Storage drawer internal depth | 500 mm | |
| Divider panel thickness | 25 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total worktop static load capacity | 235 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 open/close cycles | |
| Recommended maximum user weight per seat | 136 kg | |
| Net workstation weight (assembled) | 155 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Applicable user count | 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core and finish | E1-grade particleboard core, thermally fused melamine surface | |
|---|---|---|
| Support frame and legs | Powder-coated cold-rolled steel, 1.5mm wall thickness | |
| Edge banding | 2mm thick PVC edge trim applied to all worktop perimeter edges | |
| Central desktop divider | Medium-density fiberboard core, fabric-wrapped acoustic surface | |
| Rear modesty panels | Powder-coated steel frame with laminated panel infill | |
| Storage pedestal construction | 18mm thick melamine-faced particleboard carcass, steel drawer slides | |
| Drawer handles | Matte black ABS plastic pull handles fitted to each drawer front | |
| Cable management components | ABS plastic grommet with brush insert, under-desk steel cable tray | |
| Pedestal support glides | Nylon adjustable leveling glides on all pedestal base corners | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable routing system | Dual desk-surface grommets feed cables to under-desk raceway for tidy cord management | |
|---|---|---|
| Storage pedestal configuration | 4 drawers (2 utility, 2 file-sized) with lockable core for secure document storage | |
| Privacy divider function | Central desktop divider blocks direct line of sight between adjacent seated users | |
| Modular connection design | Pre-drilled frame holes allow connection to additional matching workstations for cluster layouts | |
| Leveling adjustment | Adjustable glides on legs and pedestal compensate for uneven floor surfaces up to 15mm | |
| Rear panel utility | Raised rear panels conceal under-desk wiring and prevent items from falling off the back edge | |
| Work surface layout | Split into two equal 1200mm wide work zones for individual user workspace | |
| Drawer operation | Full-extension ball-bearing slides allow 100% drawer access for easy file retrieval | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Provides two dedicated work positions with privacy dividers for staff seating zones | |
|---|---|---|
| Small team workspaces | Integrated storage reduces need for separate cabinets in compact office layouts | |
| Startup and co-working spaces | Modular design allows reconfiguration as team size changes over time | |
| Administrative department zones | Durable work surface and lockable storage support daily paperwork and file handling | |
| Call center seating areas | Dividers reduce visual distraction for staff handling extended phone or computer tasks | |
| Temporary project offices | Flat-pack design allows fast deployment and relocation between project sites |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance verification | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and clearance requirements for seated use | |
| EN 13722:2004 | Office furniture storage units performance and safety requirements for the drawer pedestal |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard for structural load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for drawer slide and pedestal load testing | |
| ANSI/BIFMA G1-2013 | Ergonomic guideline for desk height and seated clearance dimensions |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and pedestal quality verification | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and structural hardware | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to all composite board components | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to worktop and pedestal core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and pedestal quality verification; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and structural hardware; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to all composite board components; 4. GB/T 4897.3-2003: Particleboard for furniture use, applicable to worktop and pedestal core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
