Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1400 x 750 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Per-workstation surface width | 700 mm | |
| Per-workstation surface depth | 700 mm | |
| Privacy divider height above desktop | 350 mm | |
| Privacy divider thickness | 30 mm | |
| Knee clearance height under desktop | 680 mm | |
| Central pedestal width | 420 mm | |
| Cable grommet opening size | 80 mm | |
| Square steel leg section size | 50 x 50 mm | |
| Edge banding thickness | 3 mm | |
| Drawer internal usable depth | 500 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 120 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 open/close cycles | |
| Recommended maximum user weight per position | 150 kg | |
| Complete workstation net weight | 180 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Manufacturer warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | 25mm E1 grade melamine laminated particleboard | |
|---|---|---|
| Support frame and legs | 1.0mm thick powder-coated cold rolled square steel | |
| Central pedestal body | 18mm melamine laminated particleboard | |
| Pedestal drawers | 18mm particleboard drawers with steel ball-bearing slides | |
| Privacy dividers | 30mm fabric-wrapped MDF core panels | |
| Edge protection | 3mm PVC heat-sealed edge banding on all exposed panel edges | |
| Cable grommets | ABS plastic rectangular cable ports | |
| Hardware components | Zinc-plated steel connector bolts, cam locks and screws | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Four desktop grommets route cables directly to under-desk space | |
|---|---|---|
| Privacy division | Two cross-desk dividers separate opposite seated users | |
| Central storage | Fixed integrated 4-drawer pedestal provides shared storage | |
| Floor leveling | Adjustable glides on all leg and pedestal bases | |
| Seating access | Four open knee wells, two per long side of the desk | |
| Modular connection | Pre-drilled frame connection points allow joining additional desk units | |
| Drawer operation | Full-extension ball-bearing slides allow full drawer access | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Ideal for high-density 4-person team work zones | |
|---|---|---|
| Call center and administrative offices | Suited for seated staff working on desktop computers | |
| Startup and co-working spaces | Flexible modular design supports small team seating | |
| Corporate back-office departments | Durable commercial construction suitable for daily long-term use | |
| Training and project team rooms | Quick reconfiguration support allows layout changes as teams change |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables: Safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables: Safety, strength and durability requirements | |
| EN 13722:2004 | Office furniture: Storage units, strength and durability |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 15102-2017 | Specification for melamine laminated wood-based panels | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture coatings | |
| GB/T 10357.1-1989 | Desk static load and stability test methods |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 15102-2017: Specification for melamine laminated wood-based panels; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture coatings; 4. GB/T 10357.1-1989: Desk static load and stability test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
