Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (WxDxH) | 2840 x 1440 x 750 mm | |
|---|---|---|
| Per-user work surface area | 1200 x 600 mm | |
| Desktop panel thickness | 25 mm | |
| Desktop-mounted privacy divider height | 400 mm | |
| Under-desk seated knee clearance height | 650 mm | |
| End storage pedestal dimensions | 600 x 450 x 650 mm | |
| PVC/ABS edge banding thickness | 2 mm | |
| Angled central steel leg diameter | 50 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Drawer internal usable depth | 400 mm | |
| Lower storage cabinet internal shelf height | 300 mm | |
| Storage pedestal leg height | 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop uniform distributed static load capacity | 120 kg | |
|---|---|---|
| Single drawer slide rated load | 25 kg | |
| Drawer slide durability cycle rating | 50000 cycles | |
| Cabinet door hinge durability cycle rating | 80000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Maximum supported user count | 2 | |
| Overall product net weight | 100 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1 grade melamine-faced MFC engineered wood, anti-scratch laminate finish | |
|---|---|---|
| Edge sealing | 2mm thick PVC edge banding, rounded profile for impact protection | |
| Central support legs | Powder-coated matte black tubular steel, angled splayed design for stability | |
| Privacy dividers | Rigid matte grey MDF panel, standoff mounted with plastic support brackets | |
| Storage cabinet carcass | Melamine-faced particleboard, dark grey side panels, light wood-grain door/drawer fronts | |
| Storage hardware | Zinc-alloy drawer pulls, silver label holders, concealed steel hinges | |
| Adjustable feet | Reinforced nylon leveling feet on leg and cabinet bases | |
| Pedestal support legs | Tapered matte black steel feet, angled for cabinet stability | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Two fixed end pedestals, each with 1 lockable top drawer and 1 lower hinged door cabinet | |
|---|---|---|
| Cable management | Two desktop cable grommets positioned centrally in each work zone for power/data routing | |
| Work surface privacy | Two shaped low desktop dividers mounted between adjacent seats to block direct sight lines | |
| Floor leveling | Adjustable threaded feet on all legs and cabinet bases to compensate for uneven office floors | |
| Assembly structure | Knock-down (CKD) construction with cam-lock and bolt fasteners for on-site assembly | |
| Storage locking | Integrated key lock on each top drawer to secure personal office valuables and documents | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Two individual work zones with sight dividers for team-based office layouts | |
|---|---|---|
| Small business and startup offices | Integrated storage reduces need for separate filing cabinets, saving floor space | |
| Call center and administration areas | Dual station layout maximizes floor space efficiency for high-density seating | |
| SOHO and home office shared spaces | Compact dual-pedestal design supports two users working from a single footprint | |
| Government and educational office spaces | Durable commercial-grade construction withstands frequent daily use in high-traffic areas |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for desktop load and stability performance | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for non-domestic seating-adjacent tables | |
| EN 13722:2004 | Office furniture storage units performance requirements, applicable for pedestal drawer/hinge durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer load, cycle life and cabinet stability verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural integrity and finish quality | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks, applicable for work surface strength and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1/E0 panel material acceptance | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable for cabinet carcass material verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural integrity and finish quality; 2. GB/T 3327-2016: Technical requirements for office desks, applicable for work surface strength and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1/E0 panel material acceptance; 4. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable for cabinet carcass material verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
