Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (W x D x H) | 2400 x 1200 x 1070 mm | |
|---|---|---|
| Work surface height above floor | 750 mm | |
| Per-user work surface dimensions | 1200 x 600 mm | |
| Knee clearance height under work surface | 680 mm | |
| Central storage pedestal dimensions | 1200 x 400 x 750 mm | |
| Privacy divider height above work surface | 320 mm | |
| Drawer internal dimensions (per drawer) | 450 x 350 x 120 mm | |
| Open storage cubby internal dimensions (per cubby) | 450 x 350 x 280 mm | |
| Leg outer spread at floor level | 580 mm | |
| Work surface panel thickness | 25 mm | |
| Metal leg tube diameter | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 100 kg | |
|---|---|---|
| Uniform static load per work surface | 120 kg | |
| Static load per lockable drawer | 30 kg | |
| Recommended maximum user weight per seat | 136 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Surface scratch resistance | Grade 2 | |
| Standard product warranty | 60 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | 25mm E1 grade melamine-faced MFC | |
|---|---|---|
| Work surface edges | 2mm PVC impact-resistant edge banding | |
| Support legs | 30mm diameter powder-coated cold-rolled steel | |
| Central pedestal panels | 18mm melamine-faced engineered wood | |
| Drawer fronts | 18mm melamine-faced MDF, light gray two-tone finish | |
| Drawer slides | Cold-rolled steel three-quarter extension ball bearing slides | |
| Privacy dividers | 25mm melamine-faced rigid composite panel, dark gray finish | |
| Privacy divider mounting brackets | Injection-molded white ABS plastic | |
| Modesty panel (central rear) | 18mm dark gray melamine-faced MFC | |
| Hardware fasteners | Zinc-plated steel allen bolt assembly hardware | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Lockable central storage | Two keyed-alike lockable drawers (one per user) for secure personal storage | |
|---|---|---|
| Open shared storage | Two open cubbies below drawers for shared office supplies or personal items | |
| Workspace privacy separation | Two curved-top rigid dividers mounted between opposite users to reduce visual distraction | |
| Cable management access | Pre-drilled cable grommet positions adjacent to each privacy divider for desktop power and data routing | |
| Knock-down assembly | Flat-packed design with bolt-together leg and pedestal connections for easy on-site assembly | |
| Smooth drawer operation | Ball-bearing slides allow drawers to open/close without binding for daily office use | |
| Leveling adjustment | Integrated adjustable glide feet on each leg base to compensate for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Provides separated individual workspaces for two employees without full cubicle walls | |
|---|---|---|
| Small business startup offices | Compact footprint integrates storage and work surfaces to maximize limited floor space | |
| Co-working space hot-desking zones | Secure lockable drawers support shared workspace use for rotating staff | |
| Back-office administrative departments | Durable construction withstands daily 8+ hour use for clerical and computer work | |
| Educational institution staff rooms | Sturdy design supports teacher grading, paperwork and computer work in shared spaces | |
| Temporary project team work zones | Modular design can be grouped with additional matching units for larger teams |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety requirements, applicable to clearance dimensions | |
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion, applicable to worktop finish |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer strength and lock performance | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and corporate responsibility |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and pedestal panels | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks and tables, applicable to structural load ratings | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office air quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and pedestal panels; 2. GB/T 3327-2017: Performance requirements for office desks and tables, applicable to structural load ratings; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office air quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
