Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4080 x 1200 x 750 mm | |
|---|---|---|
| Per-seat work surface width | 1360 mm | |
| Per-user work surface depth | 600 mm | |
| Desktop privacy divider height above surface | 450 mm | |
| Privacy divider width per divider | 1200 mm | |
| Under-desk drawer pedestal height | 600 mm | |
| Seated knee clearance height under desk | 650 mm | |
| Knee well opening width per user position | 680 mm | |
| Tabletop thickness | 25 mm | |
| A-frame leg tube wall thickness | 1.8 mm | |
| Support beam cross-section | 50 x 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Drawer front panel thickness | 18 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Total unit net weight | 260 kg | |
|---|---|---|
| Desktop uniform static load capacity per seat | 100 kg | |
| Total work surface usable area | 4.9 sqm | |
| Recommended maximum user weight per seat | 120 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Steel frame static load rating for full assembly | 600 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 25mm melamine-faced particle board | |
|---|---|---|
| End support frame | Powder-coated cold-rolled steel A-leg | |
| Support beams | Rectangular powder-coated steel tube | |
| Privacy dividers | Matte off-white MDF panel | |
| Cabinet side panels | Light gray melamine-faced engineered wood | |
| Upper drawer fronts | Off-white melamine-faced engineered wood | |
| Lower drawer fronts | Light oak wood-grain melamine-faced engineered wood | |
| Accent hardware | Orange-finish metal or hard plastic | |
| Desk foot glides | Hard plastic non-marking glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Workstation layout | Back-to-back 2-row linear arrangement | |
|---|---|---|
| Visual privacy | 3 upright desktop dividers | |
| Personal storage | 3 integrated under-desk pedestal units | |
| Cable management | Recessed cable pass-through under dividers | |
| Modular assembly | Knock-down bolted connection system | |
| Floor leveling | Adjustable non-marking glides on all base points | |
| Drawer operation | Side-mounted quiet ball-bearing drawer slides | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Accommodates 6 employees in dense, space-efficient linear seating arrangements | |
|---|---|---|
| Call center and administrative work zones | Provides partial visual privacy and dedicated personal storage per user | |
| Startup and co-working flexible spaces | Modular construction supports reconfiguration as team sizes change | |
| Corporate back-office departments | Durable commercial-grade construction suitable for high-traffic daily use | |
| Educational institution staff offices | Standard work height and dimensions support long-duration seated work |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables and desks safety requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables safety, strength and durability | |
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2017: Performance requirements for office desks; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
