Automatic mm / inch conversion · Core engineering specifications
| Overall L-shaped footprint | 1600 x 1600 x 750 mm | |
|---|---|---|
| Main work surface depth | 600 mm | |
| Left storage return width | 1200 mm | |
| Left storage return depth | 600 mm | |
| Under-desk knee clearance height | 620 mm | |
| Under-desk knee clearance width | 800 mm | |
| Desktop panel thickness | 30 mm | |
| Edge band thickness | 2 mm | |
| Rear privacy divider height | 200 mm | |
| Privacy divider thickness | 25 mm | |
| Support leg tube wall thickness | 1.5 mm | |
| Open CPU bay internal dimensions | 500 x 250 x 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 159 kg | |
|---|---|---|
| Lockable drawer slide static load | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Cable grommet diameter | 60 mm | |
| Integrated cable tray static load | 5 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Recommended user weight capacity | 136 kg | |
| Product net weight | 77 kg | |
| Leveling foot adjustment height | 10 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1 grade engineered wood with matte cream melamine finish | |
|---|---|---|
| Storage return carcass | E1 grade engineered wood with matching matte cream finish | |
| Drawer front accent strip | Terracotta brown PVC accent trim | |
| Support legs | Powder-coated light cream steel with terracotta joint accents | |
| Rear privacy divider | MDF core wrapped in brown woven fabric upholstery | |
| Adjustable feet | Nylon-tipped steel glide feet | |
| Drawer lock hardware | Zinc alloy keyed cam lock | |
| Drawer slides | Cold-rolled steel ball-bearing slides | |
| Cable management clips | Orange ABS plastic clips | |
| Edge banding | 2mm thick matching cream PVC edge trim | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Work surface configuration | Fixed-height L-shaped layout for single-user executive work | |
|---|---|---|
| Left return storage | One key-locking upper drawer for secure office supply storage | |
| CPU storage bay | Open lower compartment sized for full-size desktop computer towers | |
| Open upper shelf | Flat open storage shelf above drawer for documents or peripherals | |
| Cable management | Rear fabric divider includes integrated cable clips for cord routing | |
| Floor leveling | Nylon-tipped adjustable feet on return base correct minor unevenness | |
| Privacy screening | Low rear upholstered divider reduces visual distraction without blocking light | |
| Surface resistance | Melamine finish resists common office stains, scratches and water rings | |
| Leg stabilization | Splayed dual steel legs distribute weight to prevent desk wobble | |
| Lockable drawer internal dimensions | 450 x 400 x 120 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Single-user workstation for manager or director level office spaces | |
|---|---|---|
| Home office workspace | Modern aesthetic suitable for dedicated home office or study use | |
| Small open-plan team work area | Low privacy divider reduces cross-desk visual distraction for individual workstations | |
| Consulting or meeting nook | Wide main surface accommodates laptop and documents for 1:1 client discussions | |
| Recommanded seating pairing | Pairs with mid-back ergonomic office chairs with 520 mm seat height | |
| Surface equipment capacity | Supports dual monitors, laptop, desk lamp and small office accessories |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and dimensional performance requirements | |
|---|---|---|
| EN 527-2:2016 | Mechanical safety requirements for fixed-height office desks | |
| EN 13722:2004 | Test methods for strength and durability of office storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for office desk products, applies to structural durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage components integrated with desks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to desk carcass and panels | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks and work tables | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels used in furniture | |
| GB/T 4897.3-2003 | Requirements for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to desk carcass and panels; 2. GB/T 3327-2017: Performance requirements for office desks and work tables; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels used in furniture; 4. GB/T 4897.3-2003: Requirements for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
