Automatic mm / inch conversion · Core engineering specifications
| overall footprint | 2400 x 1200 x 750 mm | |
|---|---|---|
| single workstation workspace | 1200 x 600 mm | |
| under-desk knee clearance height | 650 mm | |
| under-desk knee clearance width | 1100 mm | |
| desktop panel thickness | 25 mm | |
| privacy divider height above desktop | 305 mm | |
| pedestal storage cabinet dimensions | 400 x 600 x 600 mm | |
| cable management vent length | 300 mm | |
| cable grommet diameter | 80 mm | |
| central support leg diameter | 50 mm | |
| edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 120 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| product net weight | 126 kg | |
| recommended user count | 2 people | |
| surface abrasion resistance | 2000 cycles | |
| warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| worktop surface | Light wood grain melamine-faced MFC panel | |
|---|---|---|
| support legs | White powder-coated steel tube | |
| end pedestal panels | White and light wood grain melamine MFC | |
| lockable drawer fronts | Sage green matte melamine MDF | |
| privacy dividers | Sage green matte MDF panel with white metal brackets | |
| cabinet base glides | Nylon adjustable levelling feet | |
| drawer locks | Zinc alloy keyed cam locks | |
| cable vent grille | White ABS plastic slotted cover | |
| edge banding | 2mm thick matching PVC edging | |
| drawer slides | Cold-rolled steel ball-bearing slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| storage configuration | Two end pedestals with lockable top drawers and lower open shelves | |
|---|---|---|
| cable management | Vertical slotted cable vent on left pedestal for concealed wiring routing | |
| levelling adjustment | Adjustable nylon feet on each pedestal base to compensate for uneven floors | |
| drawer security | Keyed cam locks on each top drawer to secure personal office items | |
| privacy screening | Two angled desktop dividers mounted between workstations to reduce visual distraction | |
| mid-span support | Dual central steel legs prevent worktop sag under heavy office equipment loads | |
| cable tray support | Underside steel cable tray rated for 10kg cable and power brick load | |
| assembly configuration | Flat-packed with cam-lock and bolted connections for on-site assembly | |
| lockable drawer front height | 120 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open plan office zones | Ideal for two-person team clusters in open plan work areas to balance collaboration and privacy | |
|---|---|---|
| small office team spaces | Suitable for startup offices and small business work areas requiring dual work positions with integrated storage | |
| call center workstations | Supports seated long-duration computer work with ergonomic knee clearance and cable management | |
| co-working flexible spaces | Fits co-working environments needing dedicated shared workstations with lockable personal storage | |
| educational staff rooms | Suitable for school and university administrative staff offices requiring durable, easy to clean surfaces | |
| recommended accessory pairing | Pair with ergonomic office chairs, under-desk cable trays and monitor arms for complete workstation setup |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance validation | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and ergonomic requirements, applicable to workspace clearance checks | |
| EN 13722:2004 | Office furniture storage units performance requirements, applicable to pedestal drawer testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to pedestal and drawer cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction and finish quality | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks, applicable to load capacity and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF material acceptance | |
| GB/T 4897.3-2018 | Particleboard specifications for furniture use, applicable to worktop and cabinet panel grades |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction and finish quality; 2. GB/T 3327-2016: Performance requirements for office desks, applicable to load capacity and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF material acceptance; 4. GB/T 4897.3-2018: Particleboard specifications for furniture use, applicable to worktop and cabinet panel grades; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
