Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (arranged) | 3300 x 2200 x 870 mm | |
|---|---|---|
| 2-seater sofa overall dimensions | 1900 x 900 x 870 mm | |
| Single armchair overall dimensions | 1050 x 900 x 870 mm | |
| Coffee table overall dimensions | 1500 x 800 x 450 mm | |
| Seat height (all seating pieces) | 450 mm | |
| Seat depth (all seating pieces) | 550 mm | |
| Seat cushion thickness | 180 mm | |
| Back cushion thickness | 150 mm | |
| Armrest width | 180 mm | |
| Sofa leg height | 120 mm | |
| Coffee table base height | 420 mm | |
| Coffee table top thickness | 30 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total seating capacity | 4 people | |
|---|---|---|
| Per-seat weight capacity | 159 kg | |
| Total sofa set static load capacity | 636 kg | |
| Sofa set total net weight | 245 kg | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seating foam density | 45 kg/m³ | |
| Seating foam rebound rate | 60% | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | 2.2mm thick brown PU faux leather | |
|---|---|---|
| Seating internal frame | 25mm thick engineered plywood with corner blocking | |
| Seat cushion core | High-density polyurethane foam wrapped in polyester fiber | |
| Back cushion core | Blown polyester fiber with foam core for soft support | |
| Seat support system | 3.8mm diameter sinuous no-sag steel springs | |
| Seating legs | 30mm diameter matte black powder-coated cylindrical steel | |
| Coffee table top | 30mm thick dark grey sintered stone with polished finish | |
| Coffee table base | Matte black MDF block pedestal with polished metal inlay accents | |
| Upholstery stitching | 8 stitches per inch matching brown bonded nylon thread | |
| Leg floor protection | Polyethylene foot glides to prevent floor scuffing | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Stationary non-reclining fixed frame for casual lounge use | |
|---|---|---|
| Tufted seat detailing | Grid-patterned channel tufting prevents cushion shifting over use | |
| Leveling adjustment | Threaded foot glides compensate for up to 10mm uneven floor height | |
| Coffee table surface | Stain-resistant non-porous stone top supports hot and cold beverage placement | |
| Upholstery maintenance | Water-repellent faux leather surface wipes clean with damp cloth | |
| Set layout flexibility | Modular standalone pieces support U-shape, linear, or separated arrangement | |
| Weight distribution | Sinuous spring support reduces pressure points during extended seating | |
| Cushion retention | Fixed seat and back cushions prevent sliding during regular use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room primary seating | Supports casual family relaxation and guest entertainment for 4 people | |
|---|---|---|
| Apartment lounge space | Low-profile block design suits contemporary minimalist interior aesthetics | |
| Small office reception area | Durable faux leather upholstery supports light commercial visitor seating | |
| Hotel guest suite lounge | Matching coordinated set creates cohesive upscale seating arrangement | |
| Open-plan media room | Deep padded cushions support extended seated viewing comfort | |
| Recommended complementary layout | Center coffee table within 450mm of seats for easy access to items | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture strength, durability and safety for domestic seating, applicable for use | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating stability test standard, applicable for product validation | |
| EN 15372:2016 | Furniture durability requirements for non-domestic seating, if used commercially |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating standard for commercial use, optional validation for contract applications |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to sofa frame construction | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing | |
| GB/T 1952.1-2012 | General technical requirements for upholstered sofas, applicable to seating durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to sofa frame construction; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing; 3. GB/T 1952.1-2012: General technical requirements for upholstered sofas, applicable to seating durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
