PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3440 × 2120 × 700 mm
Overall assembled set dimensions (3-seat + 2-seat + chaise)	3440 x 2120 x 700 mm
3-seat straight sofa unit dimensions	2400 x 950 x 700 mm
2-seat straight sofa unit dimensions	1800 x 950 x 700 mm
Single open-arm chaise unit dimensions	1050 x 1700 x 700 mm
Seat height from floor	420 mm
Seat depth per seating position	950 mm
Seat width per individual position	730 mm
Backrest height above seat	280 mm
Armrest/end panel height	420 mm
Rounded end panel inset depth	120 mm
Seat Cushion Thickness	180 mm
Back Cushion Thickness	160 mm
Leg Height / Floor Clearance	160 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total sofa set net weight	260 kg
Weight capacity per seating position	113 kg
Total static load capacity for full set	680 kg
Seat foam density	45 kg/m³
Seat foam thickness	150 mm
Backrest foam thickness	100 mm
Seam stitch pitch	8 mm
Recommended warranty period for residential/light commercial use	36 months
Seat Foam Density / Rebound	40 kg/m³ / 60%
Upholstery Abrasion Reference	Fabric 60000 cycles; leather-class cover 1.4 mm

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Internal structural frame	Kiln-dried solid hardwood + 18mm plywood, moisture content ≤12%
Seat support system	8-gauge sinuous steel springs + 50mm elastic webbing grid
Upholstery material	1.4mm thick top-grain leather match, light beige finish with matching contrast piping
End panel insets	Dark smoked oak veneer over MDF core, matte lacquer finish
Seat cushion filling	High-resilience polyurethane foam wrapped in 100g Dacron batting
Backrest cushion filling	Blended 30kg/m³ foam + down-alternative fiber fill
Modular connecting hardware	Zinc-plated steel interlocking connector brackets
Floor contact base	Non-marking black felt glide strips along full bottom perimeter
Included accent pillows	100% polyester woven covers, 450x450mm size, fiber-filled
Timber Frame Section / Moisture	Primary section ≥30 × 50 mm; recommended moisture 12%
Spring / Webbing Specification	Sinuous spring wire 4 mm; elastic webbing 70 mm wide
Leg Connector Specification	Reference M8-M10 with at least 1 mechanical fixing per leg

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular configuration	3 independent units connect via under-seat metal brackets, allowing layout rearrangement
Cushion design	All seat and back cushions are loose, reversible for even wear over time
Cushion cover removal	Hidden zippers along cushion seams allow removal for spot cleaning
Floor installation	No leg assembly required; units sit directly on floor after placement
Load distribution	Full perimeter base frame distributes weight evenly across floor surface
Seating capacity	6 individual seating positions across the 3-unit set
Chaise function	Single chaise unit provides extended leg rest for reclined lounge seating
Cushion Service Configuration	Recommended 2removable/replaceable cushion methods

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Module Carton Dimensions	2200× 1050× 850 mm
Reference Packaging Volume	1.8 m³/item
Reference Packaged Gross Weight	110 kg/item

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

High-end residential living room	Open conversational layout suits large open-plan living spaces for guest entertaining
Executive office reception area	Low-profile sophisticated design creates a welcoming premium space for visitor seating
Luxury hotel lobby lounge	Durable construction and elegant neutral finish suits high-traffic public lounge areas
High-end residential penthouse lounge	Floor-sitting minimalist silhouette complements contemporary panoramic-view interiors
VIP lounge in commercial facilities	Modular layout can be rearranged to suit varying event seating requirements

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 12520:2015	Furniture – Strength, durability and safety for domestic seating, applicable to structural performance
EN 1021-1:2014	Upholstered furniture flammability – cigarette ignition resistance, applicable to upholstery materials

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to internal wood frame
GB 20400-2006	Limit of harmful substances in leather and fur, applicable to upholstery leather
GB/T 1952.1-2012	Test methods for sofas, applicable to structural durability and load testing

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal wood frame;
2. GB 20400-2006: Limit of harmful substances in leather and fur, applicable to upholstery leather;
3. GB/T 1952.1-2012: Test methods for sofas, applicable to structural durability and load testing;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · MS-LP-001-BGE

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · MS-LP-001-BGE

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · MS-LP-001-BGEOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Low-Profile Beige Modular Sectional Sofa Set (model MS-LP-001-BGE) presents a streamlined, floor-standing minimalist silhouette defined by soft rounded closed arms and a warm light beige upholstery finish accented with matching contrast piping. The set comprises three independent units— a 3-seat straight sofa, a 2-seat straight sofa, and a single open-arm chaise— that lock together with discrete under-seat hardware to form a cohesive L-shaped layout, with dark smoked oak veneer end insets adding a subtle refined textural contrast at unit edges. No leg assembly is required; units rest directly on the floor, supported by non-marking black felt glide strips along the full bottom perimeter that protect floor surfaces and evenly distribute weight across contact points. Built for long-term regular use, the sofa’s internal structure relies on a kiln-dried solid hardwood frame reinforced with plywood, with moisture content controlled to prevent warping. Seat support is provided by sinuous steel springs paired with an elastic webbing grid, topped with high-resilience polyurethane seat cushions wrapped in soft Dacron batting, and back cushions filled with a blend of supportive foam and plush down-alternative fiber. The 1.4mm top-grain leather-match upholstery balances soft hand feel with durable wear resistance, while hidden zippers on all loose, reversible cushions allow cover removal for spot cleaning, and regular cushion rotation supports even wear over time. The integrated chaise unit offers extended leg rest space for relaxed reclined seating, with six dedicated individual seating positions across the full set. Matching 450mm fiber-filled accent pillows with woven polyester covers are included to complement the neutral upholstery. This sofa set is well suited for a range of premium residential and commercial spaces. In high-end residential living rooms and penthouse lounges, its low, unobtrusive profile complements open-plan and panoramic-view interiors while supporting comfortable guest entertaining. In executive office reception areas, luxury hotel lobby lounges, and commercial VIP spaces, its neutral elegant finish and reconfigurable modular design adapt to both permanent visitor seating layouts and adjusted arrangements for special events, while its robust construction stands up to consistent high-traffic use. For procurement planning, note that the set ships in two cartons, with a reference assembly time of 40 minutes per set. Weight capacity per seating position supports regular adult use, and the full perimeter base design makes the set compatible with a range of floor types without concentrated point loading. The light beige neutral finish coordinates easily with a broad spectrum of interior color palettes, eliminating the need for custom upholstery coordination for most standard premium fit-outs.

Low-Profile Beige Modular Sectional Sofa Set with Rounded Closed Arms Specifications
