Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3600 × 2400 × 750 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total seating capacity | 4 adults | |
|---|---|---|
| Individual seat static load rating | 120 kg per seat | |
| Complete four-seat set static load rating | 480 kg | |
| Integrated side table distributed load | 25 kg per table | |
| Coffee table distributed top load | 35 kg | |
| net seating weight | 96 kg | |
| Recommended minimum circulation zone around set | 900 mm | |
| Fabric abrasion acceptance target | 50,000 Martindale cycles | |
| Seam slip resistance acceptance target | 6 mm maximum | |
| Warranty baseline | 36 months |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Woven contract-grade fabric over the dark gray high-back panels | |
|---|---|---|
| Seat and inner-back upholstery | Woven fabric in lime green or red over padded cushions | |
| Cushion structure | 120 mm molded or layered polyurethane foam seat pad with fiber-topped back cushions | |
| Internal support frame | Kiln-dried hardwood or engineered-wood seat rails with webbing or board support | |
| Integrated tabletops | White laminate or melamine-faced board with impact-resistant edge banding | |
| Coffee table top | White laminate or painted composite panel with straight edge |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Conversation configuration | Two facing two-seat sofa modules create a four-person meeting cluster with a central shared table | |
|---|---|---|
| Integrated side work surface | Each sofa includes a white side-level surface between or beside seats for cups, documents, and mobile devices | |
| High-back privacy surround | Continuous upholstered sides and back provide acoustic softening and visual separation in open offices | |
| Fixed non-reclining seats | Cushions and backrests are stationary with no visible recline, swivel, or folding mechanism |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office breakout and collaboration area | Suitable for short informal meetings, laptop work, and visitor waiting because the four seats face a shared table | |
|---|---|---|
| Open-plan lounge or reception zone | High upholstered backs define a semi-enclosed seating island without requiring architectural partitions |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
