Automatic mm / inch conversion · Core engineering specifications
| 3-seater bench overall dimensions | 1820 x 690 x 840 mm | |
|---|---|---|
| Single armchair overall dimensions | 750 x 750 x 840 mm | |
| Individual seat width per seating position | 540 mm | |
| Seat height from floor to cushion top | 450 mm | |
| Seat cushion depth | 460 mm | |
| Backrest total height from seat surface | 420 mm | |
| Armrest height from floor | 630 mm | |
| 2-tier coffee table overall dimensions | 1000 x 600 x 450 mm | |
| Coffee table lower shelf height from floor | 120 mm | |
| Perforated steel back vent panel height | 180 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Per-seat static load capacity | 150 kg | |
|---|---|---|
| Set total net weight (seating + table) | 120 kg | |
| Total seating capacity for full set | 5 persons | |
| PU upholstery abrasion resistance | 50000 double rubs | |
| Seat foam density | 45 kg/m³ | |
| Seat foam thickness | 80 mm | |
| Frame static load rating for welded structure | 750 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating support frame | 2.0mm thick cold-rolled steel with chrome plating | |
|---|---|---|
| Seat and back upholstery | 1.0mm thick black PU leather over foam padding | |
| Mid-back vent panel | 1.5mm thick perforated cold-rolled steel mesh | |
| Armrest pads | Dark brown padded faux leather over steel arm supports | |
| Coffee table top | 8mm thick clear tempered safety glass | |
| Coffee table lower shelf | 15mm thick black engineered wood with matte finish | |
| Coffee table frame | 1.5mm thick chrome-plated tubular steel with rounded edge trim | |
| Coffee table mobility components | 50mm diameter swivel nylon casters at base corners | |
| Seating leg feet | Non-slip rubber floor protection pads | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating frame structure | Fixed welded bolted steel frame with no recline or swivel mechanisms | |
|---|---|---|
| Back ventilation feature | Perforated steel mid-back panel allows continuous air circulation | |
| Coffee table mobility | Four swivel casters enable easy repositioning for cleaning or layout changes | |
| Armrest support | Fixed height integrated steel armrests with padded tops support seated entry and exit | |
| Lower shelf storage | Fixed lower shelf on coffee table holds reading materials or guest items | |
| Surface maintenance | Smooth PU leather and glass surfaces wipe clean with standard disinfectant | |
| Floor protection | Rubber leg pads on all seating prevent scratching hard flooring | |
| Seat segmentation | Individual padded seat/back sections on 3-seat bench prevent cross-contact between adjacent guests | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office reception lobbies | Formal conversational seating layout for greeting and short-term guest waiting | |
|---|---|---|
| Corporate waiting areas | Durable easy-to-clean surfaces suitable for daily visitor traffic | |
| Medical clinic or service center waiting zones | Ventilated supportive seating for extended guest stays | |
| Public institutional visitor spaces | Fixed sturdy frame resists heavy use in high-foot-traffic environments | |
| Small business meeting lounge areas | Matching coordinated set creates a professional cohesive meeting space | |
| Open plan breakout areas | Mobile coffee table allows flexible reconfiguration for casual discussion | |
| Recommended complementary configuration | Position 1200mm from entryway to maintain clear pedestrian circulation paths | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Performance requirements for non-domestic visitor and waiting area seating | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety requirements for non-domestic tables | |
| EN 1022:2018 | Stability testing standard for all seating in commercial environments |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Performance standard for lounge and public area seating applications | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Performance standard for desk and occasional tables used in office environments |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to steel frame seating and tables | |
|---|---|---|
| GB 17927.1-2011 | Upholstered furniture fire safety for public space seating components | |
| GB/T 35607-2017 | Green product evaluation standard applicable to low-VOC furniture materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to steel frame seating and tables; 2. GB 17927.1-2011: Upholstered furniture fire safety for public space seating components; 3. GB/T 35607-2017: Green product evaluation standard applicable to low-VOC furniture materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
