Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1270 × 710 × 450 mm | |
|---|---|---|
| Tabletop thickness | 19 mm | |
| Base frame wall thickness | 50 mm | |
| Under-table recess height | 280 mm | |
| Under-table recess depth | 610 mm | |
| Floor clearance under base plinth | 10 mm | |
| Top surface overhang | 20 mm | |
| Inner recess width | 1170 mm | |
| Base plinth height | 150 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop distributed static load | 80 kg | |
|---|---|---|
| Product net weight | 38 kg | |
| Surface scratch resistance | 2000 cycles | |
| Surface water resistance rating | 24 hour spot resistance | |
| Recommended maximum item weight per placement | 15 kg | |
| Structural frame load rating | 120 kg | |
| Recommended service life | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | High-density MDF board | |
|---|---|---|
| Tabletop finish | Matte light gray polyurethane lacquer | |
| Frame construction | Block-style engineered wood frame | |
| Base plinth trim | Matching matte light gray finished engineered wood | |
| Recessed inner panel | Darker gray matte engineered wood panel | |
| Edge treatment | Square eased edge profile | |
| Connector hardware | Steel cam lock and dowel connectors | |
| Surface coating thickness | 0.15 mm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Tabletop use | Fixed flat surface for holding drinks, decor, and reading materials | |
|---|---|---|
| Under-table space | Open unobstructed recess for visual lightness and foot clearance | |
| Surface maintenance | Wipe-clean matte finish resistant to common household spills | |
| Placement flexibility | Freestanding design suitable for centering in seating groups | |
| Leveling adjustment | Fixed base with optional hidden floor glides | |
| Assembly requirement | Partial knock-down assembly for frame and top | |
| Color option availability | Available in light gray, white, black, and beige finishes | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room use | Positioned in front of 3-seat sofas to serve lounge seating groups | |
|---|---|---|
| Office reception lounge use | Placed between visitor armchairs in corporate reception areas | |
| Hotel lobby lounge use | Installed in guest seating zones for upscale contemporary hospitality interiors | |
| Recommended seating configuration | Paired with one 3-seat sofa and two single armchairs for balanced layout | |
| Recommended flooring type | Suitable for placement on low-pile carpet, hardwood, or polished tile floors | |
| Surface use suitability | Supports display of decorative objects, tea sets, books, and small table lamps |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic furniture safety requirement for tables | EN 12521:2015 | |
|---|---|---|
| Furniture surface resistance to cold liquids | EN 12720:2009+A1:2013 | |
| Formaldehyde emission for wood-based panels | EN 13986:2004+A1:2015 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| General technical requirement for wooden furniture | GB/T 3324 | |
|---|---|---|
| Formaldehyde emission limit for wood-based panels | GB 18580 | |
| Surface coating adhesion test for furniture | GB/T 4893.4 |
This product must meet the following technical requirements: 1. General technical requirement for wooden furniture: GB/T 3324; 2. Formaldehyde emission limit for wood-based panels: GB 18580; 3. Surface coating adhesion test for furniture: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
