Automatic mm / inch conversion · Core engineering specifications
| Overall 3+1+1 set required footprint | 3200 x 2800 x 850 mm | |
|---|---|---|
| Three-seat sofa dimensions | 2200 x 950 x 850 mm | |
| Single armchair dimensions | 900 x 900 x 850 mm | |
| Square glass coffee table dimensions | 800 x 800 x 450 mm | |
| Seat height (all seating units) | 450 mm | |
| Seat depth (all seating units) | 600 mm | |
| Backrest height (all seating units) | 450 mm | |
| Armrest height above seat | 180 mm | |
| Sofa leg height | 150 mm | |
| Coffee table tempered glass thickness | 6 mm | |
| Clearance under coffee table | 120 mm | |
| Per-seat usable seat width | 580 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set packaged gross weight | 200 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Foam density (seat cushions) | 55 kg/m³ | |
| Foam resilience rate | 60% | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Seating cycle durability rating | 40000 cycles | |
| Total seating capacity | 5 adults | |
| Standard commercial warranty | 3 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | Light beige scratch-resistant PU leather | |
|---|---|---|
| Seat cushion filling | High-density high-resilience polyurethane foam | |
| Backrest filling | 40mm thick medium-density polyurethane foam | |
| Seating inner frame | Kiln-dried solid hardwood inner frame | |
| Seating support legs | 1.2mm thick powder-coated black steel tube legs | |
| Coffee table top | Clear tempered safety glass | |
| Coffee table base | 1.5mm thick chrome-plated steel geometric sled base | |
| Stitching detail | 20mm uniform seam pitch along upholstery edges | |
| Floor protection | Non-marking plastic glides on all leg bases | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed stationary 3-seat sofa plus 2 independent single armchairs | |
|---|---|---|
| Armrest design | Integrated fixed padded armrests on all seating units | |
| Coffee table design | Stationary low-profile table with open sled base | |
| Assembly requirement | Knock-down assembly required for legs and table base | |
| Cleaning compatibility | Smooth non-porous upholstery wipes clean with standard commercial disinfectants | |
| Upholstery customization | Available in 30+ standard color options including gray, black, and beige | |
| Seating structure | No recline, tilt, or adjustable position mechanisms | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Office reception waiting areas | Suitable for 25㎡ corporate lobby spaces seating up to 5 guests | |
|---|---|---|
| 4S store customer waiting zones | Durable easy-clean upholstery appropriate for high-traffic automotive retail | |
| Small business meeting lounge spaces | Formal minimalist design supports casual client discussion and short meetings | |
| Medical clinic waiting rooms | Smooth wipeable surfaces meet public space hygiene requirements | |
| Government service hall visitor areas | Neutral light tone matches formal public space aesthetic standards | |
| Recommended supporting accessories | Pair with 900mm minimum clearance around group for accessible guest circulation |
EU Market Access Requirements* EN Standards
| EN 13759:2004 | Applies to stability and strength requirements for domestic and contract seating | |
|---|---|---|
| EN 12521:2015 | Applies to mechanical safety requirements for non-domestic furniture tables | |
| EN 1022:2018 | Applies to stability testing for upholstered commercial seating units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Applies to durability and safety for lounge and public reception seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Applies to performance requirements for freestanding office tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden furniture frames used in seating | |
|---|---|---|
| GB 28007-2011 | Applies to safety requirements for upholstered furniture for public commercial use | |
| GB 15763.2-2005 | Applies to safety glazing requirements for tempered glass table tops |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden furniture frames used in seating; 2. GB 28007-2011: Applies to safety requirements for upholstered furniture for public commercial use; 3. GB 15763.2-2005: Applies to safety glazing requirements for tempered glass table tops; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
