Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1650 × 840 × 830 mm | |
|---|---|---|
| Overall two-seater sofa dimensions | 1650 x 840 x 830 mm | |
| Overall single-seater armchair dimensions | 900 x 840 x 830 mm | |
| Seat height for both seating units | 450 mm | |
| Seat depth for both seating units | 580 mm | |
| Backrest height above seat | 380 mm | |
| Armrest height above floor | 620 mm | |
| Overall oval coffee table dimensions | 1300 x 700 x 430 mm | |
| Coffee table lower shelf clearance | 150 mm | |
| Angled steel leg height for sofas | 150 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight | 180 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seat foam density | 45D | |
| Seat foam thickness | 120 mm | |
| Back foam thickness | 80 mm | |
| Foam rebound rate | 40% | |
| Frame structural warranty | 5 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Sofa inner frame | Kiln-dried solid hardwood, 30mm section, moisture content ≤12% | |
|---|---|---|
| Seat and back cushion fill | High-density polyurethane foam, no sinuous spring support | |
| Seating upholstery | 1.2mm thick matte PU leather, stain-resistant commercial grade | |
| Armrest caps | Walnut-toned wood veneer over MDF, rounded edge profile | |
| Sofa support legs | 20mm diameter dark powder-coated angled steel legs, floor protection glides | |
| Armchair outer arm detail | Vertical channel-stitched upholstery, 80mm stitch pitch | |
| Coffee table top | Walnut wood-grain veneer over 25mm thick MDF, rounded oval edges | |
| Coffee table base | Cream matte painted MDF, dual base (block pedestal + open lower shelf) | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | 1 single-seat armchair + 1 two-seat sofa, arranged for face-to-face reception interaction | |
|---|---|---|
| Coffee table open shelf | Lower open storage shelf for magazines, brochures or small decorative items | |
| Floor protection | All sofa legs fitted with non-marking plastic glides to prevent floor scratching | |
| Upholstery maintenance | Stain-resistant PU surface allows wipe-clean maintenance for high-traffic areas | |
| Assembly delivery | Seating and table delivered fully assembled for immediate installation | |
| Color customization | Light beige finish standard, custom RAL color options available for bulk project orders | |
| Seat ergonomics | Fixed upright seat angle of 5 degrees to support comfortable short-stay seating | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception areas | Formal neutral styling suitable for greeting clients and visitors | |
|---|---|---|
| Beauty salon and lounge waiting areas | Soft comfortable seating with easy-clean surface for high-turnover use | |
| Executive floor lounge spaces | Coordinated set provides cohesive professional aesthetic for internal break areas | |
| Small conference breakout spaces | Compact 3-person seating supports informal small group discussions | |
| Public service waiting zones | Durable commercial construction withstands frequent daily public use |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture - Visitor chairs, applicable to reception seating performance requirements | |
|---|---|---|
| EN 15372:2008 | Furniture - Strength, durability and safety for non-domestic seating |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Standard for lounge and public seating, applicable to performance benchmarking | |
|---|---|---|
| ANSI/BIFMA X7.1-2023 | Standard for furniture durability and stability for public area seating |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to table base and wood components | |
|---|---|---|
| GB/T 19001-2016 | Quality management system requirement for commercial furniture manufacturing | |
| GB 18584-2001 | Limit of harmful substances for wooden furniture interior materials, applicable to MDF components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to table base and wood components; 2. GB/T 19001-2016: Quality management system requirement for commercial furniture manufacturing; 3. GB 18584-2001: Limit of harmful substances for wooden furniture interior materials, applicable to MDF components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
