Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 850 × 820 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| 3-seater sofa total weight | 125 kg | |
|---|---|---|
| Single armchair weight | 48 kg | |
| Coffee table weight | 32 kg | |
| Seat static load capacity per seat | 150 kg | |
| Total recommended occupancy | 5 people | |
| Surface abrasion resistance (upholstery) | 50000 rub cycles | |
| Frame service life | 8 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and backrest padding | 40 kg/m³ high-density polyurethane foam | |
|---|---|---|
| Upholstery covering | 1.2 mm thick matte beige faux leather | |
| Internal seating frame | 18 mm thick engineered wood framing | |
| Sofa support legs | 1.2 mm thick matte silver powder-coated steel | |
| Coffee table top | 12 mm thick sintered stone with light grey stone finish | |
| Coffee table frame | 1.5 mm thick brushed stainless steel tubing | |
| Decorative throw pillows | 25 kg/m³ soft foam with matching faux leather cover | |
| Stitching detail | 8 mm seam pitch visible on armrest panels | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed seating configuration | Non-reclining fixed-position design | |
|---|---|---|
| Coffee table dual storage tiers | Upper serving top and lower open metal shelf | |
| Levelling feet on legs | Adjustable levelling glides on all metal leg bases | |
| Stain-resistant upholstery surface | Wipe-clean faux leather finish for commercial maintenance | |
| Modular set layout flexibility | Units can be arranged in L-shape, linear or facing configuration | |
| Floor clearance under seating | 120 mm gap under sofa base for robot vacuum access | |
| Armrest integrated padding | Fully padded armrests matching seat upholstery | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate reception lobbies | Formal neutral design for waiting areas in modern office towers | |
|---|---|---|
| Executive office waiting zones | Compact comfortable seating for visitors outside private offices | |
| High-end lounge common areas | Durable easy-clean surface for daily use by staff and guests | |
| VIP visitor meeting spaces | Coordinated matching set presents professional uniform appearance | |
| Modern serviced apartment common rooms | Contemporary neutral finish complements minimalist interior palettes | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Applicable strength/durability standard for non-domestic seating | |
|---|---|---|
| EN 15372:2016 | Applicable safety standard for non-domestic tables |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Applicable durability standard for lounge/public seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Applicable performance standard for occasional tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable as general quality standard for wooden furniture framing | |
|---|---|---|
| GB 20400-2006 | Applicable leather/faux leather limit test for harmful substances |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable as general quality standard for wooden furniture framing; 2. GB 20400-2006: Applicable leather/faux leather limit test for harmful substances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
