Product supplierRectangular Wood-Top Metal-Frame Coffee Table with Open Lower Shelf, E0-grade particleboard core
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 480 mm | |
|---|---|---|
| tabletop thickness | 19 mm | |
| leg cross-section | 40 x 20 mm rectangular steel tube | |
| lower shelf clearance above floor | 120 mm | |
| clearance between top and lower shelf | 280 mm | |
| tabletop edge radius | 15 mm | |
| lower shelf panel thickness | 16 mm | |
| leg wall thickness | 1.2 mm | |
| floor clearance under lower shelf | 60 mm | |
| lower shelf usable width | 1080 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| net product weight | 24 kg | |
|---|---|---|
| tabletop static distributed load capacity | 113 kg | |
| frame finish scratch resistance | 2000 cycles | |
| laminate surface abrasion resistance | 300 revolutions | |
| product service life (commercial use) | 5 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop substrate | E0-grade particleboard core | |
|---|---|---|
| tabletop finish | Walnut wood-grain high-pressure laminate with PVC edge banding | |
| support frame and legs | Powder-coated matte silver steel tubing | |
| lower shelf panel | Matching wood-grain laminate over particleboard | |
| foot pads | Felt-lined non-slip plastic glides | |
| connecting hardware | Zinc-plated steel bolt and cam lock connectors | |
| frame surface treatment | Electrostatic powder coating | |
| edge banding thickness | 1 mm | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| tabletop surface function | Flat stable surface for beverage service, decorative items and reading materials | |
|---|---|---|
| lower open shelf function | Open storage for magazines, brochures and small reception accessories | |
| floor protection function | Felt glides on all four leg bases | |
| structural stability design | Dual horizontal crossbars connect left and right leg assemblies | |
| assembly requirement | Knockdown assembly with included hex key hardware | |
| surface maintenance | Stain-resistant laminate surface wipes clean with damp cloth | |
| leveling adjustment | Fixed-height glides maintain even placement on level commercial flooring | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| shipping carton dimensions | 1150 x 650 x 130 mm | |
|---|---|---|
| shipping gross weight | 27 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| office reception lounge | Centered between guest seating for beverage service and visitor brochure placement | |
|---|---|---|
| corporate executive lounge | Complements leather lounge seating for informal meeting and break use | |
| high-end residential living room | Pairs with upholstered sofas and armchairs for everyday living area use | |
| hotel lobby waiting area | Durable construction withstands high-traffic public use and frequent cleaning | |
| private club lounge | Low-profile design maintains open sightlines across seating groups | |
| recommended pairing | Matches 3-seat sofa and two single armchairs in coordinated upholstery |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Furniture – Strength, durability and safety for non-domestic tables | |
|---|---|---|
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables, lounge table reference |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable as reference for commercial lounge table performance | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Sustainability standard for furniture, optional for eco-friendly procurement requirements |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate and finish | |
|---|---|---|
| GB/T 4893.8-2985 | Surface abrasion resistance test method for furniture finishes, applicable to laminate top |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate and finish; 2. GB/T 4893.8-2985: Surface abrasion resistance test method for furniture finishes, applicable to laminate top; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
