Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2200 x 880 x 850 mm | |
|---|---|---|
| Single armchair overall dimensions | 920 x 850 x 840 mm | |
| Seat height from floor | 430 mm | |
| Seat depth (usable) | 580 mm | |
| Backrest total height | 420 mm | |
| Armrest height from floor | 630 mm | |
| Large coffee table overall dimensions | 1300 x 700 x 450 mm | |
| Small side end table overall dimensions | 600 x 600 x 550 mm | |
| Leg spread width at floor (seating units) | 750 mm | |
| Lower storage shelf height (coffee table) | 120 mm | |
| Armrest width (outer to inner) | 120 mm | |
| Wall clearance required for seating | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set weight (sofa + 2 chairs + 2 tables) | 235 kg | |
|---|---|---|
| 3-seater sofa static load capacity | 450 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam compression set resistance (70C/22h) | 8 % | |
| Suitable total seating capacity per set | 5 persons | |
| Seam stitch durability | 60000 double rubs | |
| Frame joint static load rating | 1200 N | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick matte grey PVC faux leather, abrasion resistance 50000 Martindale cycles | |
|---|---|---|
| Cushion core padding | 45kg/m³ high-resilience polyurethane foam, 120mm thick seat cushion, 80mm thick back cushion | |
| Internal seating frame | 25mm x 25mm square carbon steel tube frame, 1.5mm wall thickness, with engineered wood corner blocking | |
| Seating support legs | 30mm x 15mm matte black powder-coated carbon steel angled splayed legs, 2mm wall thickness, floor protection glides | |
| Small accent lumbar cushions | Matching grey faux leather cover, 30kg/m³ soft polyester fiber fill | |
| Large coffee table top | 8mm thick black tempered safety glass, polished edges | |
| Small side table top | 25mm thick high-gloss black engineered wood, scratch-resistant melamine finish | |
| Table support frames and bases | Matte black powder-coated 2mm thick carbon steel X-frame design, lower open storage shelf on coffee table | |
| Table foot glides | 50mm diameter adjustable nylon glides, non-marking, 10mm height adjustment | |
| Seat deck support | 8mm thick elastic webbing straps spaced 80mm apart, secured to steel frame | |
| Seam construction | Nylon bonded thread stitching, 8mm seam pitch, reinforced stress points at arm and cushion edges | |
| Armrest internal structure | 20mm thick engineered wood padding substrate wrapped in 20mm soft foam layer under upholstery |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed non-reclining upright position, optimized for formal visitor and executive reception use | |
|---|---|---|
| Lumbar support | One removable matching faux leather accent cushion per seating unit (1 cushion per chair, 2 cushions on 3-seater) for adjustable lower back support | |
| Coffee table storage | Integrated lower open storage shelf under the glass top, sized to hold magazines, documents or small office accessories | |
| Floor protection | All seating and table legs fitted with non-marking nylon glides to prevent scratching polished tile, stone or hardwood office flooring | |
| Level adjustment | Table legs include 10mm of adjustable height to accommodate uneven office floor surfaces, eliminating wobble | |
| Upholstery maintenance | Stain-resistant non-porous faux leather surface, wipeable with standard neutral office cleaning products, no specialized fabric cleaning required | |
| Modular arrangement | All seating units are freestanding, allowing flexible reconfiguration for different room layouts or event setups | |
| Cable management (tables) | Open frame design allows loose routing of power or data cables for table lamps or device charging without cutting into surfaces | |
| Seating positioning | Fixed non-reclining upright 100° seat-to-back angle, optimized for formal visitor and executive reception use | |
| Cable routing (tables) | Open frame design allows loose routing of power or data cables for table lamps or device charging without modifying surfaces | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Total shipping cartons per full set | 8 cartons | |
|---|---|---|
| Largest carton dimensions (3-seater sofa) | 1850 x 780 x 620 mm | |
| Total shipment gross weight | 270 kg | |
| Total shipment CBM | 2.7 cbm | |
| Required assembly time per full set | 120 minutes | |
| 20ft GP container loading quantity | 22 sets | |
| 40ft HQ container loading quantity | 54 sets | |
| Internal packaging materials | 50mm thick expanded polystyrene edge protection, 0.12mm PE plastic wrap, 5-layer corrugated cartons, hardware packed in sealed labeled polybags | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Executive office reception areas | Sized to fit 5 visitors in formal corporate lobbies or executive floor waiting zones, matching a professional minimalist aesthetic | |
|---|---|---|
| Open plan office breakout zones | Durable wipeable upholstery withstands high daily traffic, providing informal seating for employee breaks or quick collaborative discussions | |
| Corporate meeting room lounge areas | Matched table set provides surfaces for beverages, documents and devices during pre-meeting waiting or informal internal discussions | |
| Hotel business center lobbies | Scratch-resistant surfaces and commercial-grade frames support continuous public use without visible wear in hotel guest reception areas | |
| Small private office guest seating | Two single armchairs paired with the side table are suitable for placement in individual executive offices for 1:1 visitor meetings | |
| Commercial showroom waiting areas | Coordinated modern design creates a polished first impression for client waiting zones in automotive, real estate or professional services showrooms | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture – Strength, durability and safety for non-domestic seating, applicable to commercial reception sofa load testing | |
|---|---|---|
| EN 1022:2018 | Furniture – Seating determination of stability, applicable to verify no tipping risk for splayed-leg reception chairs | |
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic and contract tables, applicable to coffee and side table structural performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for lounge and public seating, applicable for static load, durability and stability testing of reception sofas | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable to structural performance of the matching reception coffee and side tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood table top durability and structural stability testing | |
|---|---|---|
| GB/T 19001-2016 | Quality management system guidance for consistent production of commercial office furniture components | |
| GB 20400-2006 | Leather and fur limit of harmful substances, applicable if genuine leather upholstery is specified, restricting formaldehyde and heavy metal content | |
| GB/T 27904-2011 | Furniture mechanical test methods for seating, static load and durability testing for sofa seat and back frames |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood table top durability and structural stability testing; 2. GB/T 19001-2016: Quality management system guidance for consistent production of commercial office furniture components; 3. GB 20400-2006: Leather and fur limit of harmful substances, applicable if genuine leather upholstery is specified, restricting formaldehyde and heavy metal content; 4. GB/T 27904-2011: Furniture mechanical test methods for seating, static load and durability testing for sofa seat and back frames; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
