PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3200 × 1050 × 720 mm
Overall 2-piece sofa set footprint	3200 x 2800 x 720 mm
Single curved sofa seat width	2400 mm
Single sofa seat depth	950 mm
Single sofa seat height from floor	420 mm
Backrest height above seat	300 mm
Armrest height above floor	720 mm
Throw pillow size	500 x 500 mm
Side end table diameter	450 mm
Side end table height	550 mm
Metal support leg thickness	12 mm
Seat cushion thickness	150 mm
Overall 2-piece seating group footprint	3200 x 2800 x 730 mm
Back Cushion Thickness	160 mm
Leg Height / Floor Clearance	160 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Single sofa unit net weight	95 kg
Single seat static load capacity	150 kg
Total sofa set seating capacity	6 persons
Cushion foam density	45 kg/m³
Fabric abrasion resistance	50000 Martindale cycles
Seat cushion rebound rate	60 %
Total seating group capacity	6 persons
Seat cushion foam density	45 kg/m³
Upholstery fabric abrasion resistance	50000 Martindale cycles
Seat Foam Density / Rebound	40 kg/m³ / 60%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Sofa outer upholstery	Textured woven light grey fabric
Seat cushion core	High-resilience polyurethane foam wrapped with soft down blend
Back cushion core	Medium-density polyurethane foam with fibre wrap
Sofa inner frame	Kiln-dried solid hardwood and engineered plywood frame
Sofa support base	Gunmetal black finished cantilever steel frame
Coffee table large top	Clear tempered glass with polished edge
Coffee table base and small nested top	Bronze brushed stainless steel
Side table top	Smoked tempered glass
Side table support column	Polished bronze stainless steel single pedestal
Accent throw pillows	Woven textile cover with feather-fibre fill
Suspension system	Sinuous steel spring support under seat cushions
Seam stitching	Matching thread with 8 stitches per 30mm seam pitch

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating configuration	Two identical curved armless sofa modules, positioned opposite to create a conversational layout
Modular flexibility	Individual sofa units can be repositioned to adapt to L-shaped, linear or floating room layouts
Throw pillow adjustability	All included accent pillows are removable and repositionable for custom comfort and styling
Coffee table nesting function	Smaller bronze-top coffee table slides fully under the larger glass-top table for space saving when not in use
Floor protection	All metal support bases include non-marking felt glides to prevent scratching hard flooring surfaces
Upholstery maintenance	Fabric covers on fixed cushions are designed for spot cleaning, removable pillow covers are dry-clean only
Weight distribution	Cantilever steel base distributes sofa weight evenly to avoid indentation on soft carpets or sensitive flooring
Surface utility	Glass and metal table surfaces are stain-resistant and water-repellent, suitable for placing beverages, reading materials and decorative objects
Layout configuration	Two identical curved armless sofa modules positioned opposite to form a closed conversational seating group
Nested table operation	Smaller bronze-top coffee table slides fully under the larger glass-top table to reduce footprint when additional surface area is not required
Pillow adjustability	All included accent pillows are fully removable and repositionable for customized back support and styling
Surface performance	Glass and stainless steel table surfaces are non-porous, stain-resistant and water-repellent, suitable for placing beverages, reading materials and decorative objects

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Total packing units	6 packages
Sofa module carton size	2450 x 1000 x 650 mm per unit
Coffee table set carton size	1850 x 950 x 450 mm
Side table set carton size	500 x 500 x 600 mm per pair
Total gross weight per full set	240 kg
Total shipment volume	4.5 CBM
40HQ container loading quantity	30 sets
On-site assembly time	60 minutes
Sofa module carton dimensions	2850 x 1100 x 700 mm per unit
Coffee table set carton dimensions	1650 x 950 x 450 mm

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Luxury residential living room	Ideal for open-plan modern living areas, the low-profile curved design creates an open conversational layout without blocking sightlines
High-end office reception area	Appropriate for executive reception lounges and VIP waiting areas, conveys refined contemporary aesthetic for corporate guest spaces
Hotel suite lounge area	Suitable for luxury hotel penthouse suites and club lounge spaces, the deep seat cushions provide extended seating comfort for guests
Show home display	Used in high-end real estate show homes to demonstrate premium residential lifestyle settings, the symmetric arrangement creates balanced visual appeal for property marketing
Open-plan penthouse seating	Floating design without required wall contact makes it suitable for placement in the center of large open rooms with views, as visible in the reference scene
Design studio waiting area	Suits creative office and design studio reception spaces, the minimalist curved form and mixed material palette aligns with contemporary design-focused environments
Open-plan residential living room	Ideal for modern living areas over 25 sqm, the low-profile curved design creates an open conversational layout without blocking cross-room sightlines
High-end corporate reception lounge	Suitable for executive reception areas and VIP waiting spaces, the neutral grey fabric and bronze metal finish conveys a refined contemporary aesthetic for corporate guest environments

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Furniture strength and durability standard	EN 16139:2013
Furniture stability standard	EN 1022:2018
Seating furniture durability standard	EN 16139:2013
Seating stability standard	EN 1022:2018
Furniture surface durability standard	EN 12720:2009+A1:2013

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Upholstered sofa safety standard	GB/T 3324
Fabric safety standard	GB 18401Category B
Formaldehyde emission standard	GB 18584
Tempered glass safety standard	GB 15763.2
Wooden furniture general technical standard	GB/T 3324
Textile safety standard	GB 18401Category B

Standardized tender description text

This product must meet the following technical requirements:
1. Upholstered sofa safety standard: GB/T 3324;
2. Fabric safety standard: GB 18401Category B;
3. Formaldehyde emission standard: GB 18584;
4. Tempered glass safety standard: GB 15763.2;
5. Wooden furniture general technical standard: GB/T 3324;
6. Textile safety standard: GB 18401Category B;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
