Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (3-seater facing 2 armchairs with table) | 3500 x 2800 x 800 mm | |
|---|---|---|
| 3-seater sofa dimensions | 2000 x 700 x 780 mm | |
| Single armchair dimensions | 830 x 770 x 800 mm | |
| Seat height (sofa and armchairs) | 430 mm | |
| Seat depth (sofa and armchairs) | 580 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height above seat | 350 mm | |
| Armrest height above floor | 620 mm | |
| Armrest width | 120 mm | |
| Leg height (seating units) | 120 mm | |
| Metal inlay side panel thickness (armchairs) | 8 mm | |
| Matching coffee table dimensions | 1300 x 700 x 450 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 185 kg | |
|---|---|---|
| 3-seater sofa static load capacity | 450 kg | |
| Upholstery Martindale abrasion resistance | 100000 cycles | |
| Foam compression set (24h, 50% compression) | 3% | |
| Upholstery color fastness to light | Grade 4 | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Product warranty | 5 years | |
| Recommended number of users per set | 5 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery surface | Dark brown 1.2mm thick PU performance leather | |
|---|---|---|
| Internal seating frame | Kiln-dried hardwood (≤9% moisture content) with 5mm multi-layer plywood reinforcement | |
| Seat core padding | 45kg/m³ high-density molded PU foam | |
| Backrest padding | 35kg/m³ medium-density PU foam with 10mm soft foam top layer | |
| Seating legs | 20mm diameter powder-coated dark steel tubing with anti-slip floor protection pads | |
| Armchair side decorative inlay | Brushed dark metal chevron (V-shape) trim over quilted leather panel | |
| Coffee table top | 12mm thick sintered stone (artificial stone) light matte finish top | |
| Coffee table base | Powder-coated dark metal panel base with decorative linear cutouts | |
| Assembly hardware | Grade 8.8 carbon steel connecting bolts with lock washers | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed stationary non-reclining upright seating layout, 1 three-seat sofa + two single armchairs | |
|---|---|---|
| Floor protection | All seating and table legs fitted with non-marking rubber anti-slip pads | |
| Coffee table function | Low central placement provides stable surface for reading materials, beverages and decor for seated guests | |
| Cleaning compatibility | Smooth non-porous leather upholstery supports wipe-down cleaning with standard commercial office disinfectants | |
| Structural stability | Fixed leg configuration delivers rigid, wobble-free seating with no moving adjustment parts | |
| Modular arrangement flexibility | Seating units can be repositioned to form alternate linear, clustered or L-shaped waiting area layouts | |
| Optional add-on compatibility | Design supports matching add-on side tables, USB charging modules or custom logo embroidery per OEM order | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Formal aesthetic coordinates with high-end office interior design for welcoming executive guests | |
|---|---|---|
| Office waiting rooms and visitor lobbies | Durable commercial-grade construction withstands continuous high-traffic daily visitor use | |
| Business lounge and VIP meeting break spaces | Upright comfortable seating supports short to medium length wait times and casual discussions | |
| Hotel executive club and business center areas | Coordinated dark brown leather finish matches premium hospitality commercial interiors | |
| Standard configuration recommendation | Pair with complementary side tables and table lamps for a fully furnished formal reception layout | |
| User target group | Commercial facilities managers procuring durable, low-maintenance formal guest seating | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 13759:2009 | Applicable European standard for domestic and contract seating stability, strength and durability requirements | |
|---|---|---|
| EN 15372:2016 | Applicable European standard for contract office furniture strength, durability and safety requirements | |
| EN 1022:2018 | Applicable European standard for seating stability testing criteria for upright formal lounge seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Applicable standard for lounge and public area seating performance, safety and durability for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Applicable standard for desk/table products performance requirements covering the matching coffee table |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for wooden and metal furniture general technical requirements, covering table structural durability | |
|---|---|---|
| GB 18584-2001 | Applicable standard for formaldehyde and heavy metal emission limits for interior wooden furniture materials | |
| GB/T 16799-2008 | Applicable standard for performance and quality requirements for polyurethane (PU) leather used in furniture upholstery |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for wooden and metal furniture general technical requirements, covering table structural durability; 2. GB 18584-2001: Applicable standard for formaldehyde and heavy metal emission limits for interior wooden furniture materials; 3. GB/T 16799-2008: Applicable standard for performance and quality requirements for polyurethane (PU) leather used in furniture upholstery; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
