Automatic mm / inch conversion · Core engineering specifications
| Full sofa set footprint (3+1+1 + coffee table, no rug) | 3200 x 2800 x 820 mm | |
|---|---|---|
| 3-seater sofa overall dimensions | 2100 x 820 x 820 mm | |
| Single armchair overall dimensions | 820 x 780 x 820 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Seat height (all seating units) | 450 mm | |
| Seat depth (all seating units) | 580 mm | |
| Back cushion height (all seating units) | 400 mm | |
| Seat cushion thickness (all seating units) | 120 mm | |
| Back cushion thickness (all seating units) | 100 mm | |
| Armrest height from floor | 620 mm | |
| Metal sofa leg height | 180 mm | |
| Coffee table top thickness | 12 mm | |
| Coffee table leg/slatted frame thickness | 20 mm square metal tube | |
| Full sofa set footprint (3+1+1 + coffee table, 600mm walkway clearance) | 3200 x 2800 x 820 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm |
Net weight / load capacity / users / durability
| Total set net weight | 185 kg | |
|---|---|---|
| Seat static load capacity per seat position | 150 kg | |
| Recommended total seated user capacity | 5 people | |
| Cushion foam density (seat) | 40 kg/m³ | |
| Cushion foam density (back) | 30 kg/m³ | |
| Foam rebound rate | 45% | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Metal frame/leg powder coat adhesion rating | Grade 0 (no flaking) per cross-hatch test | |
| Suggested product warranty for commercial use | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat outer shell/armrests | Light grey matte faux leather/performance fabric upholstery | |
|---|---|---|
| Seat cushion upholstery | Sage green matte faux leather/performance fabric upholstery | |
| Back cushion covers | Light grey matte faux leather/performance fabric upholstery | |
| Internal seating frame | 20 mm diameter welded steel tube frame | |
| Sofa and chair legs | 1.5mm thick matte black powder coated tapered metal legs | |
| Seat support deck | 12mm thick multi-layer plywood board | |
| Coffee table top | 12mm thick white sintered stone with faint marble veining | |
| Coffee table frame | 20mm square matte black powder coated steel tube | |
| Leg foot pads | 10mm thick non-slip non-marking rubber pads | |
| Stitching details | 8 stitches per inch matching thread | |
| Throw pillow (per armchair) | 1 piece matching light grey upholstered pillow, 450x450mm | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration flexibility | 3 individual units (3-seat sofa + 2 single armchairs) that can be rearranged to fit different reception room layouts | |
|---|---|---|
| Removable cushion covers | All back and seat cushions have hidden zipper closures to allow removal for spot cleaning or replacement | |
| Floor clearance under seating | 180mm open gap between seat base and floor | |
| Coffee table storage design | Open lower slatted frame with no closed shelves | |
| Surface stain resistance | Upholstery and coffee table top have impermeable surfaces that can be wiped clean with standard disinfectant wipes | |
| Floor protection | All legs are fitted with non-marking rubber feet that prevent scuffing on polished tile, terrazzo, or sealed concrete flooring | |
| Cushion support performance | High resilience foam core prevents permanent indentation of more than 10mm after repeated use | |
| Set alignment design | All seating units share identical leg style, arm profile and color scheme to create a coordinated visual look in professional office spaces | |
| Coffee table open storage | Open lower slatted frame with no closed door panels | |
| Cushion indentation resistance | High resilience foam core limits permanent indentation to 10mm after 30000 compression cycles | |
| Set coordinated design | All seating units share identical leg style, 80mm wide arm profile and two-tone color scheme | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons (full set) | 6 cartons | |
|---|---|---|
| Largest carton dimensions (3-seater sofa frame) | 1850 x 680 x 420 mm | |
| Total shipping gross weight (full set) | 210 kg | |
| Total shipping volume (CBM) | 1.28 CBM | |
| On-site assembly time (2 workers, standard tools) | 50 minutes | |
| 20ft GP container loading quantity (full sets) | 22 sets | |
| 40ft HQ container loading quantity (full sets) | 54 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for building lobby, visitor waiting and guest meeting zones, presents a professional modern aesthetic that aligns with contemporary office design | |
|---|---|---|
| Open plan office informal meeting zones | Can be arranged in small breakout spaces for impromptu 5person discussions, provides comfortable seating without overly residential appearance | |
| Shared co-working space waiting lounges | Durable construction and stain-resistant surfaces support high daily turnover of visitors, neutral two-tone colorway matches varied co-working interior palettes | |
| Medical/financial office patient/client waiting rooms | Easy to clean surfaces, supportive seating and stable construction meet the requirements of public-facing service spaces where hygiene and durability are priorities | |
| Recommended companion configuration | Pair with 1200x600mm matching slatted coffee table as shown, plus optional 1.8x2.7m low-pile area rug to define the seating zone in open plan spaces | |
| Compatible floor types | Suitable for installation on polished concrete, large format tile, terrazzo, and low-pile commercial carpet, with non-marking feet that do not damage hard flooring | |
| Corporate office reception lobbies | Suitable for building entry, visitor waiting and guest greeting zones, presents a professional modern aesthetic aligned with contemporary glass-and-tile office design | |
| Open plan office informal breakout zones | Can be arranged in small cluster layouts for impromptu 5-person discussions, provides upright supportive seating without recline features for short work conversations |
EU Market Access Requirements* EN Standards
| Office furniture seating strength and stability | EN 16139:2013 | |
|---|---|---|
| Furniture surface resistance to cold liquids | EN 12720:2009+A1:2013 | |
| Non-domestic seating strength and stability | EN 16139:2013 |
Standards applicable to China-market projects
| General technical requirement for upholstered furniture | GB/T 3324 | |
|---|---|---|
| Upholstered furniture safety for public/office use | GB 28007 | |
| Formaldehyde emission limits for furniture | GB 18584 | |
| Metal furniture coating performance | GB/T 3323 | |
| General technical requirement for wood furniture | GB/T 3324 | |
| Upholstered furniture for public use safety | GB 28007 |
This product must meet the following technical requirements: 1. General technical requirement for upholstered furniture: GB/T 3324; 2. Upholstered furniture safety for public/office use: GB 28007; 3. Formaldehyde emission limits for furniture: GB 18584; 4. Metal furniture coating performance: GB/T 3323; 5. General technical requirement for wood furniture: GB/T 3324; 6. Upholstered furniture for public use safety: GB 28007; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
