Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seater sofa dimensions | 2300 x 900 x 850 mm | |
|---|---|---|
| Single armchair dimensions | 950 x 900 x 850 mm | |
| Seat height from floor | 420 mm | |
| Seat depth | 550 mm | |
| Backrest height | 430 mm | |
| Armrest height above seat | 180 mm | |
| Cantilever base front clearance | 120 mm | |
| Main coffee table dimensions | 1300 x 700 x 450 mm | |
| Lower coffee table shelf dimensions | 800 x 500 x 50 mm | |
| Side table dimensions | 700 x 700 x 550 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Set total net weight range | 145 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Total seating capacity | 5 people | |
| Cushion foam density | 45 kg/m³ | |
| Foam compression set resistance | 10% | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Cantilever frame static load test | 300 kg per seat | |
| Cantilever frame static load rating | 300 kg per seat | |
| Tempered glass table top impact resistance | 100 J | |
| Seam tensile strength | 180 N |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Black smooth faux leather (PU) | |
|---|---|---|
| Seat padding | 45kg/m³ high-density polyurethane foam | |
| Armrest structure | Padded wood composite frame wrapped in matching black faux leather | |
| Sofa and armchair base | Polished chrome-plated bent steel cantilever frame | |
| Coffee table top | 10mm thick tempered black glass | |
| Coffee table support structure | Black powder-coated steel Z-frame and lower base shelf frame | |
| Side table top | Dark wood veneer top on polished chrome metal frame | |
| Upholstery stitching | Reinforced bonded polyester stitching at 8 stitches per inch | |
| Frame internal structure | 20mm thick plywood seat and back support boards | |
| Seat and back padding | 45 kg/m³ high-density polyurethane foam, 120mm seat thickness, 80mm back thickness | |
| Seating internal support board | 20mm thick multi-layer plywood, 12% moisture content, glued and screwed to frame | |
| Main coffee table top | 10mm thick tempered black glass, polished flat edges, glossy non-porous finish |
Adjustment / rotation / tilt / mobility / storage features
| Cantilever seating support | Fixed welded chrome steel frame provides slight flexible give for comfort without adjustment mechanisms | |
|---|---|---|
| Easy under-seat cleaning access | Open cantilever base with no center supports allows full access for vacuuming and floor cleaning under all seating units | |
| Coordinated modular arrangement | 3-seat sofa, two armchairs and two tables can be arranged in U-shape, linear or separate configurations to fit different reception room layouts | |
| Scratch-resistant table surfaces | Tempered glass tops resist minor scratches from cups, keys and office items for long-lasting appearance in high traffic areas | |
| Stain-resistant upholstery surface | Smooth faux leather upholstery can be wiped clean of spills and stains with a damp cloth, suitable for public visitor areas | |
| Fixed upright seating posture | 95-degree backrest angle supports formal upright seating for business meetings without recline functionality, maintaining professional appearance during visitor interactions | |
| Cantilever flex support | Fixed welded chrome steel frame provides 10mm controlled flexible deflection under occupant weight for comfort, no adjustable moving parts | |
| Modular layout flexibility | Matching 3-seat sofa, two armchairs, coffee table and side table can be arranged in U-shape, linear or separated zone configurations to fit reception room layouts from 25m² to 60m² | |
| Stain-resistant upholstery maintenance | Smooth non-porous PU faux leather surface can be fully cleaned of liquid spills and common office stains with a damp cloth and neutral detergent in 30 seconds | |
| Fixed upright posture support | 95-degree fixed backrest angle with structured 80mm back foam padding supports formal upright seating for meeting durations up to 90 minutes without slumping | |
| Lower shelf integrated storage | Coffee table lower 8mm glass shelf provides 200mm vertical clearance for storing magazines, visitor brochures and small reception items out of immediate sight | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total number of shipping cartons | 7 cartons | |
|---|---|---|
| Largest carton dimensions (3-seat sofa) | 2350 x 950 x 650 mm | |
| Total shipment gross weight | 180 kg | |
| Total shipment volume | 2.8 CBM | |
| assembly time | 60 minutes | |
| 20ft container loading capacity | 10 sets | |
| 40ft HQ container loading capacity | 25 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Formal black leather-look styling projects professional image for visitor waiting and executive meeting spaces, coordinated set completes room layout without additional furniture sourcing | |
|---|---|---|
| Office lounge and waiting zones | Durable high-traffic construction withstands daily use by employees and visitors, stain-resistant upholstery reduces facility maintenance workload | |
| Small conference and meeting rooms | Upright supportive seating suitable for short to medium length meetings, modular arrangement fits rooms from 40square meters | |
| Hotel business center lobbies | Consistent professional appearance matches commercial hotel design schemes, easy to clean surfaces support high guest turnover | |
| Government and institution visitor areas | Formal neutral design works with standard office decor, durable construction meets public facility usage requirements | |
| Recommended complementary decor | Low-pile commercial carpet, neutral wall finishes and green potted plants to match the staged corporate environment shown in product imagery | |
| Office employee and visitor waiting zones | 50000 Martindale abrasion-resistant upholstery and high-density foam withstand daily high-traffic use by employees and visitors, stain-resistant surface reduces facility maintenance workload | |
| Small formal conference and meeting rooms | Fixed upright 95-degree seating angle supports short to medium length meetings up to 90 minutes, modular arrangement fits rooms designed for 6person meetings |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Office furniture office work chairs safety requirements, referenced for structural stability and load testing of seating units even for reception use | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating determination of stability, applicable to verify the cantilever frame does not tip during normal use | |
| EN 12520:2015 | Furniture strength, durability and safety requirements for domestic seating, referenced for cyclic load testing of sofa cushions and frames | |
| EN 12600:2002 | Glass in building impact test requirements for pendulum body test, applicable to tempered glass table tops for break safety | |
| EN 15372:2016 | Furniture - Durability requirements for non-domestic tables, applicable to coffee and side tables for vertical load and edge impact resistance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Lounge and public seating standard, referenced for static load, durability and stability testing for commercial reception application | |
|---|---|---|
| ANSI/BIFMA X5.41-2019 | Standard for occasional use tables, applicable to glass coffee and side tables for load capacity and edge safety requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal plywood frame components, verifying dimensional stability and structural safety | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable to chrome cantilever frames and steel table supports, verifying weld strength and finish durability | |
| GB 18584-2001 | Applicable standards and test results require confirmation | |
| GB/T 19995.1-2005 | Performance requirements for upholstered furniture seating, applicable to static load, durability and impact testing of sofa seats and backs |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal plywood frame components, verifying dimensional stability and structural safety; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable to chrome cantilever frames and steel table supports, verifying weld strength and finish durability; 3. GB 18584-2001: Applicable standards and test results require confirmation; 4. GB/T 19995.1-2005: Performance requirements for upholstered furniture seating, applicable to static load, durability and impact testing of sofa seats and backs; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
