Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2300 × 900 × 820 mm | |
|---|---|---|
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended total seating load | 480 kg | |
|---|---|---|
| Three-seat sofa distributed static load | 300 kg | |
| Single chair static load | 160 kg | |
| Seat foam density | 35 kg/m3 | |
| Back cushion foam density | 28 kg/m3 | |
| Seat foam thickness | 120 mm | |
| Back cushion thickness | 180 mm | |
| Coffee table top distributed load | 40 kg | |
| Three-seat sofa net weight | 75 kg | |
| Set seat capacity | 5 seats |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Slate-blue smooth leather or leather-match cover with stitched side panels; exact hide or PU composition requires supplier BOM confirmation. | |
|---|---|---|
| Seat cushions | High-resilience polyurethane foam with a soft upper padding layer, based on the smooth tailored cushion appearance. | |
| Back cushions | Padded foam-and-fiber back cushions with separate loose-cushion construction visible on the three-seat sofa. | |
| Internal frame | Kiln-dried hardwood and engineered-wood load-bearing frame with corner blocking recommended; internal structure is not visible. | |
| Support legs | Black powder-coated angular metal legs with a tapered profile, visible on all seating pieces. | |
| Coffee table frame | Black rectangular metal leg-and-rail frame with an open underside, clearly visible below the tabletop. |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Three-seat sofa and two matching armchairs provide five independent seats for formal reception or lounge meetings. | |
|---|---|---|
| Arm support | Continuous padded square track arms on all three seating pieces provide forearm support and a structured side boundary. | |
| Base design | Four outward-angled metal legs per seating unit lift the upholstered body and simplify floor cleaning with 180 mm clearance. | |
| Coffee table service | Central open-frame table provides cup, document and decor placement without obstructing circulation between the seats. |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Complete set gross weight | 178 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate reception area | Formal visitor waiting zone where the three-seat sofa anchors the wall and two chairs create a balanced five-person conversation layout. | |
|---|---|---|
| Executive lounge or meeting suite | Used for short informal discussions, guest reception or tea service with the central table supporting documents and refreshments. |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Seating safety recommendation | EN 16139 | |
|---|---|---|
| Upholstered furniture flammability recommendation | EN 1021and EN 1021 | |
| Formaldehyde panel recommendation | EN 13986 | |
| Furniture surface resistance recommendation | EN 12720 and EN 12722 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Furniture structural safety recommendation | GB/T 10357.2 | |
|---|---|---|
| Furniture strength and durability recommendation | GB/T 10357.3 | |
| Formaldehyde emission recommendation | GB 18584 | |
| Fabric and leather colorfastness recommendation | GB/T 26703 |
This product must meet the following technical requirements: 1. Furniture structural safety recommendation: GB/T 10357.2; 2. Furniture strength and durability recommendation: GB/T 10357.3; 3. Formaldehyde emission recommendation: GB 18584; 4. Fabric and leather colorfastness recommendation: GB/T 26703; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
