Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 450 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Leg section diameter | 25 mm | |
| Leg wall thickness | 3 mm | |
| Leg splay offset from table corner | 80 mm | |
| Gold tip height on leg | 30 mm | |
| Undertable floor clearance | 120 mm | |
| Tabletop corner radius | 5 mm | |
| Leg mounting plate size | 80 x 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table top static distributed load | 50 kg | |
|---|---|---|
| Net product weight | 28 kg | |
| Recommended maximum placemat/object coverage | 70% of tabletop area | |
| Adjustable foot vertical adjustment range | 10 mm | |
| Surface stain resistance rating | Grade 5 | |
| Leg finish scratch resistance | 2H pencil hardness | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 12mm thick sintered stone slab | |
|---|---|---|
| Tabletop backing | 5mm thick honeycomb steel reinforcement panel | |
| Leg structure | 3mm thick carbon steel tube | |
| Leg foot tips | Polished gold-plated stainless steel caps | |
| Mounting hardware | M8 zinc-plated steel bolts and lock washers | |
| Adjustable glides | Nylon base non-marking glides | |
| Edge treatment | Polished eased stone edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly method | Knock-down assembly with included hex key | |
|---|---|---|
| Leveling adjustment | Rotating foot glides adjust up to 10mm | |
| Surface function | Non-porous smooth top supports drinks, reading materials and decor | |
| Load distribution | Four splayed legs spread weight evenly across floor | |
| Edge protection | Eased stone edges prevent impact injury | |
| Finish performance | Baked enamel leg finish resists scuffs from daily cleaning | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception lounge | Placed centrally in front of guest seating for beverage and document placement | |
|---|---|---|
| Corporate executive waiting area | Coordinates with upholstered lounge seating for professional guest experience | |
| Hotel lobby seating zone | Durable easy-clean surface suitable for high-traffic public hospitality spaces | |
| Modern residential living room | Matches contemporary light luxury upholstery and neutral interior palettes | |
| Open-plan breakout area | Low profile supports casual collaboration and refreshment placement for staff | |
| Showroom display setting | Complements modern upholstered seating sets for cohesive furniture vignettes |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety for non-domestic tables | |
| EN 13722:2004 | Furniture - Test methods for surface resistance to cold liquids |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety checks | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for backing panel quality verification | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 1732-2020 | Paint film impact resistance test method, applicable for leg finish durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety checks; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for backing panel quality verification; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 4. GB/T 1732-2020: Paint film impact resistance test method, applicable for leg finish durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
