Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 850 × 780 mm | |
|---|---|---|
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| 3-seater sofa net weight | 75 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Total set recommended user capacity | 5 people | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 30 kg/m³ | |
| Frame static load rating | 500 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | 1.2mm thick matte faux leather | |
|---|---|---|
| Seat core padding | High-density polyurethane foam | |
| Backrest padding | Medium-density polyurethane foam | |
| Support legs | 1.2mm thick matte black powder-coated steel tube | |
| Decorative accent straps | Wear-resistant coral orange faux leather | |
| Accent strap fasteners | Brushed metal circular buttons | |
| Coffee table top | 12mm thick sintered stone with white marble finish | |
| Coffee table support frame | Brushed stainless steel legs and cross-brace | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed non-reclining seat structure | Tight upholstered construction maintains formal reception silhouette | |
|---|---|---|
| Floor clearance for cleaning | 150mm open space under all units allows robot vacuum access | |
| Coordinated modular set layout | Symmetric arrangement with 3-seater centered and armchairs flanking coffee table | |
| Stain-resistant upholstery surface | Smooth faux leather finish allows wipe-clean maintenance for public areas | |
| Leveling foot design | Small non-marking feet on each leg protect hard flooring | |
| Fixed coffee table placement | Stable cross-braced metal base prevents tipping during regular use | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception areas | Formal low-profile design suits visitor waiting spaces with professional aesthetic | |
|---|---|---|
| Executive lounge areas | Coordinated color scheme complements premium office interior design schemes | |
| Small business meeting waiting zones | 5-person capacity supports daily visitor traffic for small teams | |
| Hotel lobby casual seating zones | Durable easy-clean upholstery withstands high-frequency public use | |
| Open plan breakout areas | Compact footprint fits flexible informal collaboration spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
