Automatic mm / inch conversion · Core engineering specifications
| Overall set layout dimensions | 2800 x 2400 x 860 mm | |
|---|---|---|
| 3-seat sofa dimensions | 2100 x 840 x 860 mm | |
| Single armchair dimensions | 720 x 670 x 830 mm | |
| Seat height for all seating units | 450 mm | |
| Seat cushion depth for all seating units | 580 mm | |
| Large nesting coffee table dimensions | 610 x 610 x 460 mm | |
| Small nesting coffee table dimensions | 500 x 500 x 430 mm | |
| Seat cushion thickness | 120 mm | |
| Back cushion thickness | 100 mm | |
| Cantilever sled base metal tube diameter | 50 mm | |
| Table top thickness | 12 mm | |
| Armrest height above seat | 180 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 220 kg | |
|---|---|---|
| Per-seat static load capacity | 181 kg | |
| Recommended maximum occupancy | 5 people | |
| Seating foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 cycles | |
| Metal base static load rating | 905 kg | |
| Table surface heat resistance | 200 °C | |
| Limited commercial warranty period | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating main upholstery | 1.2mm thick matte PU leather in light taupe | |
|---|---|---|
| Arm outer accent panels | Patterned dark grey PU leather with geometric V-shaped design | |
| Seating inner frame | 18mm thick plywood/solid hardwood frame | |
| Cushion filling | High-density polyurethane foam with doll cotton topper | |
| Seating base frame | 2mm thick powder-coated steel cantilever sled base | |
| Floor contact glides | Non-marking PVC pads on all base feet | |
| Coffee table tops | 12mm thick matte sintered stone in light grey finish | |
| Coffee table bases | 2mm thick powder-coated metal trapezoidal pedestal bases | |
| Back cushion tufting | Matching PU fabric-covered buttons at each cushion center | |
| Upholstery stitching | 4 stitches per centimeter reinforced seam construction | |
| Frame joinery hardware | Zinc-plated steel bolts and corner brackets | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating position adjustment | Fixed non-reclining, non-swivel stationary design | |
|---|---|---|
| Coffee table nesting function | Small table slides fully under larger table to save floor space | |
| Floor protection feature | Non-marking PVC glides prevent scratches on hard lobby flooring | |
| Seating stability design | Cantilever sled base distributes weight evenly without rocking | |
| Surface maintenance feature | Stain-resistant PU upholstery wipes clean with standard disinfectants | |
| Table surface performance | Scratch and heat resistant sintered stone top resists daily use damage | |
| Layout flexibility | Modular 3+1+1 configuration can be rearranged for different lobby sizes | |
| Assembly requirement | Minimal on-site assembly for attaching base feet to seating units | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Corporate office lobby reception areas | Formal U-shaped conversation layout supports guest waiting and greeting | |
|---|---|---|
| Executive floor visitor waiting zones | Neutral taupe finish matches modern professional office decor schemes | |
| High-rise office lounge spaces | Cantilever base and clean lines suit contemporary commercial interior design | |
| Meeting room breakout spaces | Seating plus tables supports casual discussion and light refreshment service | |
| Public service waiting areas | Stain-resistant, durable surfaces withstand high daily visitor traffic | |
| Recommended complementary decor | Low-profile potted plants and reading materials on tables for guest use | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Applicable to safety requirements for non-domestic seating used in public spaces | |
|---|---|---|
| EN 15372:2016 | Applicable to strength, durability and safety requirements for non-domestic tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Applicable to performance and safety standard for lounge and public office seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Applicable to performance and safety standard for desk/occasional office tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to wooden frame general furniture quality and structural safety requirements | |
|---|---|---|
| GB 18584-2001 | Applicable to interior decoration material limit of harmful substances in wood furniture | |
| GB/T 16799-2008 | Applicable to performance requirements for polyurethane leather used in furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to wooden frame general furniture quality and structural safety requirements; 2. GB 18584-2001: Applicable to interior decoration material limit of harmful substances in wood furniture; 3. GB/T 16799-2008: Applicable to performance requirements for polyurethane leather used in furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
